Audi S6 C6 (2006-2008) left front level control system sensor Wiring diagrams

BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/VIO WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DYNAMIC CORNERING LIGHT MOTOR FUSE FUSE 9 GRN WIRE GRN/GRY WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/VIO WIRE HEADLAMP BEAM ADJUSTMENT MOTOR HEADLAMP RANGE CONTROL MODULE (ABOVE GLOVE BOX) HEADLAMP RANGE/CORNERING LAMP CONTROL MODULE HEADLAMP REFLECTOR ADJUSTMENT SOLENOID HID LAMP HID LAMP CONTROL MODULE HOT W/ POWER SUPPLY RELAY ENERGIZED LEFT FRONT LEVEL CONTROL SYSTEM SENSOR LEFT REAR LEVEL CONTROL SYSTEM SENSOR ORG/BLK WIRE ORG/BRN WIRE RED WIRE RED/YEL WIRE RIGHT FRONT FOG LAMP RIGHT FRONT SIDE MARKER LAMP RIGHT HEADLIGHT ASSEMBLY SWIVEL MODULE POSITION SENSOR TURN VIO WIRE VIO/BLK WIRE VIO/YEL WIRE WHT WIRE WHT/BLU WIRE WHT/GRY WIRE YEL WIRE YEL/WHT WIRE

BLK WIRE BLK/RED WIRE BLK/YEL WIRE BLU WIRE BLU/VIO WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRL FUSE FUSE 9 GRN WIRE GRN/WHT WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/VIO WIRE HEADLAMP BEAM ADJUSTMENT MOTOR HEADLAMP RANGE CONTROL MODULE (ABOVE GLOVE BOX) HEADLAMP REFLECTOR ADJUSTMENT SOLENOID HID LAMP HID LAMP CONTROL MODULE HOT W/ POWER SUPPLY RELAY ENERGIZED LEFT FRONT LEVEL CONTROL SYSTEM SENSOR LEFT REAR LEVEL CONTROL SYSTEM SENSOR ORG/BLK WIRE ORG/BRN WIRE RED WIRE RED/YEL WIRE RIGHT FRONT FOG LAMP RIGHT FRONT SIDE MARKER LAMP RIGHT HEADLIGHT ASSEMBLY TURN VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/VIO WIRE WHT/YEL WIRE YEL WIRE YEL/WHT WIRE
