Audi S6 C6 (2006-2008) interior lights, mirrors system wiring diagram
This page shows the only wiring diagram for the component.interior lights, mirrors system, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
interior lights, mirrors system wiring diagram (1 of 1)
BACKREST
BLK WIRE
BLK/BRN WIRE
BLU/BRN WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER DOOR CONTROL MODULE (IN LEFT FRONT DOOR)
DRIVER'S POWER SEAT SWITCH
DRIVER'S SEAT MEMORY PROGRAM CONTROL
FORE/AFT
FUSE 39
FUSE 44
FUSE PANEL B
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRY WIRE
GRY/RED WIRE
GRY/WHT WIRE
HEAD RESTRAINT
HEIGHT
HOT AT ALL TIMES
INTERIOR LIGHTS, MIRRORS SYSTEM
ORG/BRN WIRE
ORG/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
TILT
WHT/RED WIRE
Go to component -> Memory systems circuit (2 of 2) -> INTERIOR LIGHTS, MIRRORS SYSTEM
