Audi S6 C6 (2006-2008) interior access/ start authorization antenna 1 Wiring diagram
This page shows the only wiring diagram for the component.interior access/ start authorization antenna 1, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram interior access/ start authorization antenna 1 (1 of 1)
9 POSITION RELAY PANEL (UNDER LEFT SIDE OF DASH)
ACCESS/START AUTHORIZATION SWITCH
AMPLIFIER 2 ANTENNA
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/YEL WIRE
DOOR LOCKS SYSTEM
DRIVER'S ACCESS/START AUTHORIZATION ANTENNA (IN LEFT REAR DOOR)
FRONT PASSENGER'S ACCESS/START AUTHORIZATION ANTENNA (REAR OF LUGGAGE COMPT)
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
GRY/GRN WIRE
GRY/RED WIRE
INTERIOR ACCESS/ START AUTHORIZATION ANTENNA 1
KEYLESS ACCESS AUTHORIZATION ANTENNA READER (ABOVE GLOVE BOX)
LUGGAGE COMPARTMENT ACCESS/START AUTHORIZATION ANTENNA
NCA WIRE
POWER DISTRIBUTION SYSTEM
POWER SUPPLY RELAY
POWER SUPPLY RELAY (TERMINAL 15)
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/YEL WIRE
STARTER RELAY
STARTER RELAY 2
STARTING/ CHARGING SYSTEM
TRANSMISSION SYSTEM
WHT WIRE
YEL WIRE
YEL/GRY WIRE
Go to component: -> Access/start circuit (2 of 2) -> INTERIOR ACCESS/ START AUTHORIZATION ANTENNA 1
