Audi S6 C6 (2006-2008) intake flap motor map controlled engine cooling thermostat Wiring diagram
This page shows the only wiring diagram for the component.intake flap motor map controlled engine cooling thermostat, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram intake flap motor map controlled engine cooling thermostat (1 of 1)
AUXILIARY ENGINE COOLANT PUMP RELAY
BLK WIRE
BRAKE BOOSTER RELAY
BRAKE PEDAL SWITCH
CAMSHAFT ADJUSTMENT VALVE 1
CAMSHAFT ADJUSTMENT VALVE 1 (EXHAUST)
CAMSHAFT ADJUSTMENT VALVE 2
CAMSHAFT ADJUSTMENT VALVE 2 (EXHAUST)
COOLANT FAN CONTROL MODULE
COOLANT FAN CONTROL MODULE 2
ENGINE COMPT POWER SUPPLY RELAY
ENGINE CONTROL MODULE (ECM)
ENGINE CONTROL MODULE I (ECM)
ENGINE CONTROL MODULE II (ECM)
FROM FUSE PANEL B (DIAGRAM 2 OF 6)
FUSE 1
FUSE 2
FUSE 3
FUSE 4
FUSE 8
FUSE 9
FUSE PANEL A FUSE 10
GRN WIRE
GRY WIRE
IGNITION COIL 10
IGNITION COIL 2
IGNITION COIL 3 IGNITION COIL 4
IGNITION COIL 5
IGNITION COIL 6 IGNITION COIL 1
IGNITION COIL 8 IGNITION COIL 7
IGNITION COIL 9
INTAKE FLAP MOTOR MAP CONTROLLED ENGINE COOLING THERMOSTAT
MOTRONIC ENGINE CONTROL MODULE RELAY
RED WIRE
RED/YEL WIRE
RELAY HOLDER (E-BOX) (IN LEFT PLENUM CHAMBER E-BOX)
TO FUSE
TRANSMISSION CONTROL MODULE (TCM)
VARIABLE INTAKE MANIFOLD RUNNER MOTOR
VIO WIRE
WHT WIRE
YEL WIRE
Go to component: -> Power distribution circuit (6 of 6) -> INTAKE FLAP MOTOR MAP CONTROLLED ENGINE COOLING THERMOSTAT
