Audi S6 C6 (2006-2008) front passenger's head curtain airbag igniter Wiring diagram

This page shows the only wiring diagram for the component.front passenger's head curtain airbag igniter, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram front passenger's head curtain airbag igniter (1 of 1)

Wiring diagram front passenger's head curtain airbag igniter for Audi S6 C6 (2006-2008)

Get access

BLK WIRE BLU WIRE BRN WIRE BRN/YEL WIRE DRIVER'S SAFETY BELT TENSIONER IGNITER 1 FRONT PASSENGER'S HEAD CURTAIN AIRBAG IGNITER FRONT PASSENGER'S SIDE AIRBAG IGNITER GRN WIRE GRY WIRE GRY/BRN WIRE GRY/RED WIRE LEFT REAR SAFETY BELT TENSIONER IGNITER NCA WIRE RED WIRE RIGHT REAR SAFETY BELT TENSIONER IGNITER SEAT OCCUPIED RECOGNITION CONTROL MODULE SEAT OCCUPIED RECOGNITION PRESSURE SENSOR SHORT CIRCUIT BRIDGE (IT SHORTS THE PINS WHEN CONNECTION IS BROKEN) SOLID STATE VIO WIRE WHT WIRE YEL WIRE YEL/BRN WIRE YEL/GRY WIRE

Go to component: -> Supplemental restraints circuit (2 of 3) -> FRONT PASSENGER'S HEAD CURTAIN AIRBAG IGNITER
