Audi S6 C6 (2006-2008) energy management control module Wiring diagrams
This page contains all the electrical diagrams for the component. energy management control module, in which he is found in the car Audi S6 C6 (2006-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram energy management control module (1 of 3)
4-POSITION RELAY & FUSE PANEL (IN RIGHT PLENUM CHAMBER E-BOX)
9 POSITION RELAY PANEL (UNDER LEFT SIDE OF DASH)
ACCESS/
AIRBAG CONTROL MODULE
BATTERY
BATTERY INTERRUPT IGNITER
BLK WIRE
BLU WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
CONTROL MODULE
CONTROL MODULE TO FUSE PANEL B (DIAGRAM 3 OF 6)
COOLANT FAN CONTROL MODULE
COOLANT FAN CONTROL MODULE 2
ENERGY MANAGEMENT CONTROL MODULE
FUSE 104
FUSE 131
FUSE 132
FUSE 133
FUSE 42
GRN WIRE
LEVELING CONTROL SYSTEM COMPRESSOR RELAY
LIGHT SWITCH ELECTRONIC PARKING BRAKE CONTROL MODULE
MAIN FUSE PANEL
MAIN FUSE PANEL (E-BOX) (IN RIGHT PLENUM CHAMBER E-BOX)
NCA WIRE
POWER SUPPLY RELAY (TERM
POWER SUPPLY RELAY (TERM 15)
RED WIRE
SELF- LEVELING SYSTEM FUSE FUSE 110
STARTER RELAY
STARTER RELAY 2
STARTING/ CHARGING SYSTEM
STEERING COLUMN ELECTRONICS SYSTEMS CONTROL MODULE
SUP- PRESSOR
TO FUSE
TO FUSE PANEL B (DIAGRAM 2 OF 6)
TO FUSE PANEL B (DIAGRAM 2 OF 6) TO FUSE PANEL B (DIAGRAM 2 OF 6)
TO FUSE PANEL B (DIAGRAM 2 OF 6) TO FUSE PANEL B (DIAGRAM 3 OF 6)
TO FUSE PANEL B (DIAGRAM 3 OF 6)
TO FUSE TO FUSE PANEL B (DIAGRAM 3 OF 6)
TO SECONDARY AIR PUMP FUSE (DIAGRAM 5 OF 6)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (1 of 6) -> ENERGY MANAGEMENT CONTROL MODULE
Wiring diagram energy management control module (2 of 3)
4-POSITION RELAY & FUSE PANEL (IN RIGHT PLENUM CHAMBER E-BOX)
ANTENNA AMPLIFIER
BLK WIRE
BLU WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
DIGITAL SOUND SYSTEM CONTROL MODULE (W/O BOSE PREMIUM PACKAGE)
ELECTRONIC PARKING BRAKE CONTROL MODULE PARKING AID CONTROL MODULE
ENERGY MANAGEMENT CONTROL MODULE
FROM FUSE
FROM MAIN FUSE PANEL (DIAGRAM 1 OF 6)
FROM RELAY & FUSE PANEL (DIAGRAM 1 OF 6)
FRONT PASS- ENGER'S DOOR CONTROL MODULE RIGHT REAR DOOR CONTROL MODULE
FUSE
FUSE 1
FUSE 1 FUSE 8 FUSE 7
FUSE 12
FUSE 2
FUSE 3 FUSE 11
FUSE 3 FUSE 4
FUSE 4
FUSE 5
FUSE 6
FUSE 6 FUSE 9
FUSE 8
FUSE 9 FUSE 7
FUSE FUSE 10
GRN WIRE
GRY WIRE
NAVIGATION SYSTEM WITH CD DRIVE CONTROL MODULE
RADIO
REAR CIGARETTE LIGHTER
REAR LID CONTROL MODULE
REAR LID CONTROL MODULE 2 COMFORT SYSTEM CENTRAL CONTROL MODULE
REAR WINDOW DEFOGGER FUSE FUSE 41
REAR WINDOW DEFOGGER RELAY
RED WIRE
RELAY & FUSE PANEL
SATELLITE RADIO AMPLIFIER
SECONDARY AIR INJECTION PUMP RELAY
SECONDARY AIR PUMP FUSE FUSE 130
SOCKET 2
TO FUSE
VIO WIRE
W/ BOSE PREMIUM PACKAGE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> ENERGY MANAGEMENT CONTROL MODULE
Wiring diagram energy management control module (3 of 3)
AIR BAG SPIRAL SPRING/RETURN SPRING W/SLIP RING
AIRBAG CONTROL MODULE (BELOW CENTER OF DASH)
BATTERY INTERRUPT IGNITER
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CENTER REAR SAFETY BELT TENSIONER IGNITER
DRIVER'S AIR BAG IGNITER
DRIVER'S AIR BAG IGNITER 2
DRIVER'S SIDE AIRBAG IGNITER
ENERGY MANAGEMENT CONTROL MODULE
FRONT PASSENGER'S AIRBAG IGNITER
FUSE 10
FUSE PANEL
GRN WIRE
GRY WIRE
HOT IN ON OR START
IGNITER 1
IGNITER 2
IGNITER FOR HEAD AIRBAG (DRIVER'S SIDE)
NCA WIRE
POWER DISTRIBUTION SYSTEM
REAR PASSENGER'S SIDE AIRBAG (DRIVER'S SIDE) IGNITER
REAR PASSENGER'S SIDE AIRBAG (FRONT PASSENGER'S SIDE) IGNITER
RED WIRE
SHORT CIRCUIT BRIDGE (IT SHORTS THE PINS WHEN CONNECTOR IS UNPLUGGED)
SOLID STATE
VIO WIRE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> ENERGY MANAGEMENT CONTROL MODULE
