Audi S6 C6 (2006-2008) driver's power seat switch Wiring diagrams

This page contains all the electrical diagrams for the component. driver's power seat switch, in which he is found in the car Audi S6 C6 (2006-2008). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram driver's power seat switch (1 of 2)

Wiring diagram driver's power seat switch for Audi S6 C6 (2006-2008)

Get access

BACKREST BLK WIRE BLK/BRN WIRE BLU/BRN WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTROL MODULE (IN LEFT FRONT DOOR) DRIVER'S POWER SEAT SWITCH DRIVER'S SEAT MEMORY PROGRAM CONTROL FORE/AFT FUSE 39 FUSE 44 FUSE PANEL B GRN WIRE GRN/BLK WIRE GRN/BRN WIRE GRY WIRE GRY/RED WIRE GRY/WHT WIRE HEAD RESTRAINT HEIGHT HOT AT ALL TIMES INTERIOR LIGHTS, MIRRORS SYSTEM ORG/BRN WIRE ORG/GRN WIRE RED/GRY WIRE RED/YEL WIRE TILT WHT/RED WIRE

Go to component: -> Memory systems circuit (2 of 2) -> DRIVER'S POWER SEAT SWITCH

Wiring diagram driver's power seat switch (2 of 2)

Wiring diagram driver's power seat switch for Audi S6 C6 (2006-2008)

Get access

BACKREST BLK WIRE BLU WIRE BRN WIRE CIRCUIT BREAKER DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTING MOTOR DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR DRIVER'S POWER SEAT ADJUSTMENT DRIVER'S POWER SEAT SWITCH DRIVER'S SEAT BACKREST ADJUSTMENT MOTOR DRIVER'S SEAT FORE/AFT ADJUSTMENT MOTOR DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR DRIVER'S SEAT INCLINATION ADJUSTMENT MOTOR FORE/AFT HEIGHT HOT AT ALL TIMES PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTING MOTOR PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTING MOTOR PASSENGER'S POWER SEAT SWITCH PASSENGER'S SEAT BACKREST ADJUSTMENT MOTOR PASSENGER'S SEAT FORE/AFT ADJUSTMENT MOTOR PASSENGER'S SEAT HEIGHT ADJUSTMENT MOTOR PASSENGER'S SEAT INCLINATION ADJUSTMENT MOTOR RED WIRE RED/WHT WIRE TILT WHT WIRE YEL WIRE

Go to component: -> Power seats circuit -> DRIVER'S POWER SEAT SWITCH
