Audi S6 C6 (2006-2008) cigarette lighter rear cigarette lighter Wiring diagram
This page shows the only wiring diagram for the component.cigarette lighter rear cigarette lighter, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cigarette lighter rear cigarette lighter (1 of 1)
ASR/ESP BUTTON
ASTRAY, CUP HOLDER LIGHT
BLU WIRE
BLU/YEL WIRE
BRN WIRE
BRN/RED WIRE
CENTER INSTRUMENT PANEL VENT LIGHT
CIGARETTE LIGHTER REAR CIGARETTE LIGHTER
COMPUTER DATA LINES SYSTEM
DISPLAY, GLOVE COMPT BUTTON
EMERGENCY FLASHER SWITCH
GARAGE DOOR OPENER CONTROL HEAD
GRY WIRE
GRY/BLU WIRE
GRY/WHT WIRE
GRY/YEL WIRE
INSTRUMENT CLUSTER CONTROL MODULE
INSTRUMENT CLUSTER OPERATION SWITCH
LEFT INSTRUMENT PANEL VENT LIGHT
LEFT REAR AIR VENT LIGHT
LEFT REAR HEATED SEAT REGULATING
LIGHT SWITCH
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PARKING BRAKE PRESSURE SWITCH
REAR WINDOW SHADE SWITCH
RIGHT CENTER AIR VENT LIGHT
RIGHT INSTRUMENT PANEL VENT LIGHT
RIGHT REAR AIR VENT LIGHT
RIGHT REAR HEATED SEAT REGULATING
ROOF ELECTRONICS CONTROL MODULE
SUNROOF SWITCH LIGHT
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE 2 (ABOVE GLOVE BOX)
VIO WIRE
WHT/GRN WIRE
YEL WIRE
Go to component: -> Instrument illumination circuit (1 of 2) -> CIGARETTE LIGHTER REAR CIGARETTE LIGHTER
