Audi S6 C6 (2006-2008) air bag spiral spring/return spring w/slip ring Wiring diagram
This page shows the only wiring diagram for the component.air bag spiral spring/return spring w/slip ring, which is found in the car Audi S6 C6 (2006-2008). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air bag spiral spring/return spring w/slip ring (1 of 1)
AIR BAG SPIRAL SPRING/RETURN SPRING W/SLIP RING
AIRBAG CONTROL MODULE (BELOW CENTER OF DASH)
BATTERY INTERRUPT IGNITER
BLK WIRE
BLK/RED WIRE
BLU WIRE
BRN WIRE
CENTER REAR SAFETY BELT TENSIONER IGNITER
DRIVER'S AIR BAG IGNITER
DRIVER'S AIR BAG IGNITER 2
DRIVER'S SIDE AIRBAG IGNITER
ENERGY MANAGEMENT CONTROL MODULE
FRONT PASSENGER'S AIRBAG IGNITER
FUSE 10
FUSE PANEL
GRN WIRE
GRY WIRE
HOT IN ON OR START
IGNITER 1
IGNITER 2
IGNITER FOR HEAD AIRBAG (DRIVER'S SIDE)
NCA WIRE
POWER DISTRIBUTION SYSTEM
REAR PASSENGER'S SIDE AIRBAG (DRIVER'S SIDE) IGNITER
REAR PASSENGER'S SIDE AIRBAG (FRONT PASSENGER'S SIDE) IGNITER
RED WIRE
SHORT CIRCUIT BRIDGE (IT SHORTS THE PINS WHEN CONNECTOR IS UNPLUGGED)
SOLID STATE
VIO WIRE
WHT WIRE
YEL WIRE
YEL/GRY WIRE
Go to component -> Supplemental restraints circuit (1 of 3) -> AIR BAG SPIRAL SPRING/RETURN SPRING W/SLIP RING
