Audi S6 C5 (1999-2004) w/ manual trans Wiring diagrams
This page contains all the electrical diagrams for the component. w/ manual trans, in which he is found in the car Audi S6 C5 (1999-2004). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ manual trans (1 of 2)
AUTOMATIC DAY/NIGHT MIRROR
BLK WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
DRIVER'S SIDE MIRROR
FUSE 11
FUSE 31
FUSE PANEL (LEFT END OF DASH)
GARAGE DOOR OPENER (IF EQUIPPED)
GRY WIRE
HOT IN RUN OR START
MULTI- FUNCTION TRANSMISSION RANGE SWITCH (CLOSED IN REVERSE)
PARK/ NEUTRAL POSITION RELAY BACK-UP LIGHT SWITCH
PASSENGER'S SIDE MIRROR
RED WIRE
SHIFT LOCK SOLENOID
TRANSMISSION CONTROL MODULE
VIO WIRE
W/ CVT AUTO TRANS
W/ MANUAL TRANS
W/ NON-CVT AUTO TRANS
WHT WIRE
YEL WIRE
Go to component -> Automatic day/night mirror circuit -> W/ MANUAL TRANS
Wiring diagram w/ manual trans (2 of 2)
3 4 (WAGON) (SEDAN)
BACK- UP LIGHT
BACK-UP LIGHT SWITCH
BLK WIRE
BLU WIRE
BRN WIRE
FUSE 31
FUSE PANEL (LEFT END OF DASH)
HOT IN RUN OR START
LEFT TAILLIGHT ASSEMBLY BACK- UP LIGHT
MULTI- FUNCTION TRANSMISSION RANGE SWITCH (CLOSED IN REVERSE)
PARK/ NUETRAL POSITION RELAY
RED WIRE
RIGHT TAILLIGHT ASSEMBLY
TRANSMISSION CONTROL MODULE
W/ CVT AUTO TRANS
W/ MANUAL TRANS
W/ NON-CVT AUTO TRANS
WHT WIRE
Go to component -> Back-up lamps circuit -> W/ MANUAL TRANS
