Audi S6 C5 (1999-2004) steering column adjustment axial motor Wiring diagrams

BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE FUSE 275 GRN/BLU WIRE GRN/YEL WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES IGNITION SWITCH KEY-IN IGNITION SWITCH MICRO CENTRAL ELECTRIC PANEL (BEHIND LEFT SIDE OF DASH) RED WIRE RED/BLU WIRE STEERING COLUMN ADJUSTMENT AXIAL MOTOR STEERING COLUMN ADJUSTMENT SWITCH STEERING COLUMN ADJUSTMENT VERTICAL MOTOR STEERING COLUMN/ BELT HEIGHT ADJUSTMENT CONTROL MODULE WHT/GRN WIRE YEL/BLU WIRE YEL/WHT WIRE

BLK WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE FUSE 14 FUSE 275 FUSE PANEL (LEFT END OF DASH) GRN WIRE GRN/BLU WIRE GRN/YEL WIRE GRY WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES IGNITION SWITCH KEY-IN IGNITION SWITCH MEMORY MIRROR CONTROL MODULE MEMORY PROGRAM SWITCH MEMORY SEAT CONTROL MODULE MEMORY SEATS CIRCUIT MICRO CENTRAL ELECTRIC PANEL (BEHIND LEFT SIDE OF DASH) RED WIRE RED/BLU WIRE RED/WHT WIRE STEERING COLUMN ADJUSTMENT STEERING COLUMN ADJUSTMENT AXIAL MOTOR STEERING COLUMN ADJUSTMENT SWITCH STEERING COLUMN/ BELT HEIGHT ADJUSTMENT CONTROL MODULE VERTICAL MOTOR VIO WIRE VIO/BLK WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/VIO WIRE YEL WIRE YEL/BLU WIRE YEL/WHT WIRE
