Audi S6 C5 (1999-2004) passenger's memory program switch Wiring diagram
This page shows the only wiring diagram for the component.passenger's memory program switch, which is found in the car Audi S6 C5 (1999-2004). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's memory program switch (1 of 1)
3 BULBS
A/C CONTROL HEAD
ASR/ESP BUTTON
BLK WIRE
BLU WIRE
BOARD COMPUTER FUNCTION SELECTOR SWITCH
BRN WIRE
CENTER INSTRUMENT PANEL VENT ILLUMINATION
CIGARETTE LIGHTER
COMBINATION PROCESSOR
CUP HOLDER ILLUMINATION
DRIVER'S HEATED SEAT ADJUSTER
DRIVER'S MEMORY PROGRAM SWITCH
EMERGENCY FLASHER SWITCH
EXTERIOR LIGHTS
FUSE 3
FUSE PANEL (LEFT END OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT PANEL LIGHT DIMMER SWITCH
LEFT INSTRUMENT PANEL VENT ILLUMINATION
LEFT REAR HEATED SEAT REGULATING SWITCH
LEVEL CONTROL SYSTEM CONTROL MODULE
LIGHT SWITCH
MIRROR ADJUSTMENT SWITCH
MULTI- FUNCTION STEERING WHEEL CONTROL MODULE RADIO
OFF HEAD PARK
PARKING AID SWITCH
PASSENGER'S HEATED SEAT ADJUSTER
PASSENGER'S MEMORY PROGRAM SWITCH
REAR CIGARETTE LIGHTER
REAR SEAT CENTER OUTLET LIGHT
REAR WINDOW SHADE SWITCH
RED WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT MAP/READING LIGHT AND LEFT FRONT READING LIGHT
RIGHT INSTRUMENT PANEL VENT ILLUMINATION
RIGHT REAR HEATED SEAT REGULATING SWITCH
STEERING WHEEL CONTROL UNIT A/C CONTROL HEAD
STORAGE TRAY ILLUMINATION
SUNROOF REGULATOR
TELEMATIC CONTROL HEAD
VIO WIRE
Go to component -> Interior lights circuit (1 of 3) -> PASSENGER'S MEMORY PROGRAM SWITCH
