Audi S5 II facelift (2019-2024) in the left rear side panel coupling point on left c-pillar Wiring diagram
This page shows the only wiring diagram for the component.in the left rear side panel coupling point on left c-pillar, which is found in the car Audi S5 II facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram in the left rear side panel coupling point on left c-pillar (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLUETOOTH ANTENNA
BRN WIRE
CENTER COUPLING POINT IN INTERIOR
COMPUTER DATA LINES SYSTEM
EMERGENCY CALL MODULE ANTENNA 2
EMERGENCY CALL MODULE SPEAKER
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
GPS ANTENNA
GPS ANTENNA (CONVERTIBLE)
GRN WIRE
IN THE LEFT REAR SIDE PANEL COUPLING POINT ON LEFT C-PILLAR
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT FRONT MICROPHONE
MICROPHONE UNIT (IN FRONT ROOF MODULE)
NCA WIRE
PNK WIRE
RED WIRE
RIGHT FRONT MICROPHONE
ROOF ANTENNA (SPORTBACK, COUPE)
TELEPHONE MICROPHONE
VIO/GRY WIRE
YEL WIRE
Go to component -> Emergency call circuit (3 of 3) -> IN THE LEFT REAR SIDE PANEL COUPLING POINT ON LEFT C-PILLAR
