Automatic a/c circuit, w/ climatronic for Audi S5 II (2016-2019)

AIR DISTRIBUTION DOOR MOTOR BLK WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON ROOF DEFROSTER DOOR MOTOR DISPLAY UNIT DRIVER SIDE SEAT VENTILATION SWITCH EVAPORATOR VENT TEMPERATURE SENSOR FRESH AIR DOOR MOTOR FRONT A/C DISPLAY CONTROL HEAD FRONT PASSENGER SIDE SEAT VENTILATION SWITCH 2 FUSE 12 FUSE 6 FUSE PANEL 2 FUSE PANEL B FUSE PANEL C (LEFT END OF DASH) GROUND DISTRIBUTION SYSTEM GRY WIRE GRY/BLK WIRE HOT AT ALL TIMES HUMIDITY SENSOR INSTRUMENT CLUSTER CONTROL MODULE LEFT FOOTWELL VENT TEMPERATURE SENSOR LEFT SEAT HEATING BUTTON ORG/BRN WIRE POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR RECIRCULATION DOOR MOTOR RED WIRE RED/BRN WIRE RELAY & FUSE PANEL 1 RIGHT FOOTWELL VENT TEMPERATURE SENSOR RIGHT SEAT HEATING BUTTON SUNLIGHT PHOTO SENSOR TEMPERATURE CONTROL DOOR MOTOR VIO WIRE VIO/WHT WIRE WHT WIRE WHT/YEL WIRE YEL WIRE YEL/GRN WIRE

A/C CLUTCH A/C COMPRESSOR REGULATOR VALVE AIR QUALITY SENSOR AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR BLK/GRN WIRE BLU/WHT WIRE BOTTOM COUPLING POINT ON LEFT A-PILLAR BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON ROOF ENGINE COOLANT LEVEL SENSOR FRESH AIR BLOWER FRESH AIR BLOWER CONTROL MODULE FUSE 1 FUSE 10 FUSE 8 FUSE PANEL 3 FUSE PANEL 4 FUSE PANEL 5 FUSE PANEL B GRN WIRE GROUND DISTRIBUTION SYSTEM GRY/BRN WIRE GRY/RED WIRE HIGH PRESSURE SENSOR HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED HUMIDITY SENSOR IN FRESH AIR INTAKE DUCT LIGHT RECOGNITION SENSOR ORG/BRN WIRE OUTSIDE AIR TEMPERATURE SENSOR RED/BLU WIRE RED/GRY WIRE RELAY & FUSE PANEL 1 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/RED WIRE VIO/WHT WIRE W/ HIGH BEAM ASSIST W/O HIGH BEAM ASSIST WHT WIRE WHT/YEL WIRE YEL WIRE YEL/VIO WIRE

AFTER-RUN COOLANT PUMP BLK/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE COOLANT SHUT-OFF VALVE FUSE 2 FUSE 3 FUSE PANEL A HOT AT ALL TIMES MAP CONTROLLED ENGINE COOLING THERMOSTAT RADIATOR FAN RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE RADIATOR FAN CONTROL MODULE 2 RADIATOR FAN FUSE N/A RED WIRE RED/BLU WIRE RED/WHT WIRE RIGHT RADIATOR FAN SUPPRESSOR W/ HOT CLIMATES W/ LOW FAN OUTPUT WHT/VIO WIRE YEL/RED WIRE YEL/VIO WIRE

2.0L TURBO 2.9L TURBO 3.0L TURBO BLK WIRE BLK/GRN WIRE BRN WIRE BRN/BLK WIRE BRN/VIO WIRE CENTER COUPLING POINT IN ENGINE/MOTOR COMPARTMENT COMPUTER DATA LINES SYSTEM CONTROL MODULE POWER SUPPLY RELAY ENERGIZED COOLANT RECIRCULATION PUMP ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON ENGINE ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET ENGINE/MOTOR CONTROL MODULE FUSE 13 FUSE 14 FUSE 8 FUSE PANEL 1 FUSE PANEL B GRN WIRE GRN/GRY WIRE GRN/WHT WIRE GRN/YEL WIRE HOT W/ MOTRONIC ENGINE PNK/WHT WIRE RED/BLU WIRE RED/VIO WIRE RELAY & FUSE PANEL 1 VIO/WHT WIRE VIO/YEL WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/VIO WIRE YEL/RED WIRE YEL/VIO WIRE
