Audi S5 II (2016-2019) red/yel Wiring diagrams

ANTI-LOCK BRAKES, EXTERIOR LIGHTS SYSTEMS ANTI-THEFT SYSTEM BLK WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BLU/BLK WIRE BLU/GRN WIRE BLU/RED WIRE BLU/VIO WIRE BRN WIRE BRN/RED WIRE BRN/YEL WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DEFOGGER, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT SYSTEMS DOOR LOCKS, ANTI-THEFT, TRUNK, TAILGATE, FUEL DOORS SYSTEMS ENGINE CONTROLS SYSTEM FUSE 11 FUSE 14 FUSE 9 FUSE PANEL 1 FUSE PANEL 3 FUSE PANEL F GRN WIRE GRN/BLK WIRE GRN/GRY WIRE GRN/RED WIRE GRN/VIO WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES LEFT REAR WINDOW BREAKAGE SENSOR ORG/BRN WIRE POWER DISTRIBUTION SYSTEM REAR WINDOW BREAKAGE SENSOR RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 2 RIGHT REAR WINDOW BREAKAGE SENSOR SPORT BACK STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM VIO WIRE VIO/BLU WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/YEL WIRE WHT WIRE WHT/GRY WIRE WHT/RED WIRE YEL WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/VIO WIRE YEL/WHT WIRE

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE COMPUTER DATA LINES SYSTEM CONVERTIBLE TOP CONTROL MODULE CONVERTIBLE TOP FRONT CLOSED POSITION SWITCH CONVERTIBLE TOP LATCH OPEN SWITCH CONVERTIBLE TOP OPERATION SWITCH CONVERTIBLE TOP STOWED POSITION SWITCH FUSE 4 FUSE 9 FUSE PANEL 3 FUSE PANEL 5 FUSE PANEL F GRN WIRE GRN/GRY WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE HOT AT ALL TIMES INTERMEDIATE POSITION BRACKET SWITCH LEFT CONVERTIBLE TOP COMPARTMENT ENCLOSURE MOTOR LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LEFT TENSIONING BOW LOWERED POSITION SWITCH ORG/BRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 2 RIGHT TENSIONING BOW LOWERED POSITION SWITCH SWITCH ILLUMINATION BULB UPPER TENSIONING BOW SWITCH VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRY WIRE

BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE CENTER COUPLING POINT IN LUGGAGE COMPARTMENT CONVERTIBLE TOP COMPARTMENT OPEN SWITCH CONVERTIBLE TOP CONTROL MODULE CONVERTIBLE TOP LATCH CLOSED LEFT SWITCH CONVERTIBLE TOP LATCH CLOSED RIGHT SWITCH CONVERTIBLE TOP LOCKING MOTOR CONVERTIBLE TOP LOCKING READINESS LEFT SWITCH CONVERTIBLE TOP LOCKING READINESS RIGHT SWITCH GRN WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE GRY/YEL WIRE LEFT COUPLING POINT IN LUGGAGE COMPARTMENT NCA WIRE POWER CONVERTIBLE TOP VALVE 1 POWER CONVERTIBLE TOP VALVE 2 POWER CONVERTIBLE TOP VALVE 3 RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE VIO/BLK WIRE VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE YEL WIRE YEL/BLK WIRE YEL/BLU WIRE YEL/GRY WIRE

BLK WIRE BLU/RED WIRE BLU/YEL WIRE BRN WIRE BRN/BLU WIRE CENTER COUPLING POINT IN LUGGAGE COMPARTMENT CONVERTIBLE TOP HYDRAULIC PUMP RELAY CONVERTIBLE TOP HYDRAULIC PUMP RELAY 2 CONVERTIBLE TOP OPERATION FUSE GRN WIRE GRN/WHT WIRE HOT AT ALL TIMES LEFT REAR WHEEL HOUSING WIRING COUPLING POINT LOWER CONVERTIBLE TOP COMPARTMENT ENCLOSURE LEFT SWITCH LOWER CONVERTIBLE TOP COMPARTMENT ENCLOSURE RIGHT SWITCH NCA WIRE REAR PASSENGER COMPARTMENT MONITORING LEFT ULTRASOUND SENSOR REAR PASSENGER COMPARTMENT MONITORING RIGHT ULTRASOUND SENSOR RED WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 2 RIGHT REAR WHEEL HOUSING WIRING COUPLING POINT VIO/BLU WIRE VIO/BRN WIRE VIO/GRN WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE

BLK WIRE BLK/VIO WIRE BLU WIRE BLU/BRN WIRE BRN WIRE BRN/GRN WIRE BRN/VIO WIRE CENTRAL LOCKING COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM CONTACT SWITCH CYLINDER DRIVER DOOR DRIVER DOOR LOCK UNIT DRIVER LOCK DRIVER SIDE DRIVER'S DOOR CONTROL MODULE DRIVER'S INTERIOR LOCKING SWITCH FUSE 14 FUSE 5 FUSE 9 FUSE PANEL 1 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL B FUSE PANEL F GRN WIRE GRN/RED WIRE HOT AT ALL TIMES LEFT FRONT DOOR COUPLING POINT LEFT REAR DOOR COUPLING POINT LEFT REAR EXTERIOR DOOR HANDLE TOUCH SENSOR MOTOR ORG/BRN WIRE ORG/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 1 RELAY & FUSE PANEL 2 RIGHT FRONT DOOR COUPLING POINT SAFE MOTOR VIO/BRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/YEL WIRE YEL WIRE YEL/GRY WIRE YEL/WHT WIRE

BLK/BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM COUPLING POINT ON ROOF FOG LAMP BUTTON FOG LAMP INDICATOR LAMP FUSE 11 FUSE 12 FUSE 13 FUSE 3 FUSE 9 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL 4 FUSE PANEL B FUSE PANEL C GRN WIRE GRY WIRE GRY/RED WIRE HEADLAMP SWITCH ILLUMINATION BULB HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED HUMIDITY SENSOR INSTRUMENT CLUSTER CONTROL MODULE LEFT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE LEFT FRONT HEADLAMP LEFT FRONT SIDE MARKER LAMP LEFT FRONT TURN SIGNAL LAMP LEFT HEADLAMP BEAM ADJUSTMENT MOTOR LEFT HEADLAMP CURRENT CODING RESISTANCE 1 LEFT HEADLAMP CURRENT CODING RESISTANCE 2 LEFT HEADLAMP CURRENT CODING RESISTANCE 3 LEFT HEADLAMP CURRENT CODING RESISTANCE 4 LEFT HEADLAMP CURRENT CODING RESISTANCE 5 LEFT HEADLAMP TEMPERATURE SENSOR 1 LEFT HEADLAMP TEMPERATURE SENSOR 2 LEFT HEADLAMP TEMPERATURE SENSOR 3 LEFT HEADLAMP TEMPERATURE SENSOR 4 LEFT HEADLAMP TEMPERATURE SENSOR 5 LEFT HIGH BEAM HEADLAMP LEFT LED HEADLAMP POWER OUTPUT MODULE 1 LEFT LIGHT CONTROL MODULE LEFT LOW BEAM HEADLAMP LEFT STATIONARY CORNERING LAMP LIGHT SWITCH ORG/BRN WIRE PARKING BRAKE INDICATOR LAMP POWER DISTRIBUTION SYSTEM RAIN/LIGHT RECOGNITION SENSOR RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 1 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE YEL/RED WIRE

AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE BLK/BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL PARKING BRAKE BUTTON FUSE 11 FUSE PANEL 1 FUSE PANEL F GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT REAR LEVEL CONTROL SYSTEM SENSOR ORG/BRN WIRE PNK WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 2 RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE RIGHT FRONT HEADLAMP RIGHT FRONT SIDE MARKER LAMP RIGHT FRONT TURN SIGNAL LAMP RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HEADLAMP CURRENT CODING RESISTANCE 1 RIGHT HEADLAMP CURRENT CODING RESISTANCE 2 RIGHT HEADLAMP CURRENT CODING RESISTANCE 3 RIGHT HEADLAMP CURRENT CODING RESISTANCE 4 RIGHT HEADLAMP CURRENT CODING RESISTANCE 5 RIGHT HEADLAMP TEMPERATURE SENSOR 1 RIGHT HEADLAMP TEMPERATURE SENSOR 2 RIGHT HEADLAMP TEMPERATURE SENSOR 3 RIGHT HEADLAMP TEMPERATURE SENSOR 4 RIGHT HEADLAMP TEMPERATURE SENSOR 5 RIGHT HIGH BEAM HEADLAMP RIGHT LED HEADLAMP POWER OUTPUT MODULE 1 RIGHT LIGHT CONTROL MODULE RIGHT LOW BEAM HEADLAMP RIGHT STATIONARY CORNERING LAMP VIO/GRN WIRE VIO/YEL WIRE W/O LEVEL CONTROL SYSTEM WHT WIRE YEL/RED WIRE

AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR AUTOMATIC HIGH BEAM ASSIST CONTROL MODULE BLK/BLU WIRE BRN WIRE COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL PARKING BRAKE BUTTON FUSE 11 FUSE PANEL 1 FUSE PANEL F GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/VIO WIRE GRY/WHT WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT LEVEL CONTROL SYSTEM SENSOR LEFT REAR LEVEL CONTROL SYSTEM SENSOR ORG/BRN WIRE PNK WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 2 RIGHT DAYTIME RUNNING LAMP, POSITION LAMP LED MODULE RIGHT FRONT HEADLAMP RIGHT FRONT TURN SIGNAL LAMP RIGHT HEADLAMP AUXILIARY FUNCTIONS POWER OUTPUT MODULE RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR RIGHT HEADLAMP CURRENT CODING RESISTANCE 1 RIGHT HEADLAMP CURRENT CODING RESISTANCE 2 RIGHT HEADLAMP CURRENT CODING RESISTANCE 3 RIGHT HEADLAMP CURRENT CODING RESISTANCE 4 RIGHT HEADLAMP FAN RIGHT HEADLAMP TEMPERATURE SENSOR 1 RIGHT HEADLAMP TEMPERATURE SENSOR 2 RIGHT HEADLAMP TEMPERATURE SENSOR 3 RIGHT HEADLAMP TEMPERATURE SENSOR 4 RIGHT HEADLAMP TEMPERATURE SENSOR 5 RIGHT HIGH BEAM HEADLAMP RIGHT LED HEADLAMP POWER OUTPUT MODULE 1 RIGHT LIGHT CONTROL MODULE RIGHT LOW BEAM HEADLAMP RIGHT MATRIX HEADLAMP POWER OUTPUT MODULE RIGHT STATIONARY CORNERING LAMP VIO/GRN WIRE VIO/YEL WIRE W/O LEVEL CONTROL SYSTEM WHT WIRE YEL/GRN WIRE YEL/RED WIRE

ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/BLU WIRE BLK/VIO WIRE BLK/YEL WIRE BRN WIRE BRN/GRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS FUSE 1 FUSE 10 FUSE 5 FUSE 9 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL B GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRY WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/WHT WIRE HEADLIGHTS SYSTEM HORNS SYSTEM HOT AT ALL TIMES NAVIGATION SYSTEM NAVIGATION, SOUND SYSTEMS ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 1 SEATS SYSTEM VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/BLU WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WHT/GRN WIRE WHT/GRY WIRE WHT/VIO WIRE WHT/YEL WIRE WIPER/WASHER SYSTEM YEL WIRE YEL/BLU WIRE YEL/GRN WIRE YEL/GRY WIRE YEL/RED WIRE YEL/WHT WIRE

AIR CONDITIONING SYSTEM ANTI-LOCK BRAKES SYSTEM BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/VIO WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA COMPUTER DATA LINES SYSTEM COOLING FANS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS FUSE 13 FUSE 15 FUSE 2 FUSE 3 FUSE 6 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL 4 FUSE PANEL B GRN WIRE GRN/RED WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HEADLIGHTS SYSTEM HOT AT ALL TIMES HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED INSTRUMENT CLUSTER SYSTEM LINES SYSTEM NAVIGATION SYSTEM ORG/BRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE PANEL 1 STARTING/CHARGING SYSTEM SUPPLEMENTAL RESTRAINTS SYSTEM VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/RED WIRE VIO/WHT WIRE VIO/YEL WIRE WARNING SYSTEMS WHT WIRE WHT/VIO WIRE WHT/YEL WIRE WIPER/WASHER SYSTEM YEL WIRE YEL/BLK WIRE YEL/VIO WIRE
