Audi S5 II (2016-2019) compartment cover locking motor Wiring diagram
This page shows the only wiring diagram for the component.compartment cover locking motor, which is found in the car Audi S5 II (2016-2019). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram compartment cover locking motor (1 of 1)
BLK WIRE
BLU/RED WIRE
BLU/YEL WIRE
BOTTOM COUPLING POINT ON LEFT A-PILLAR
BRN WIRE
COMPARTMENT COVER CLOSED SWITCH
COMPARTMENT COVER LOCKING MOTOR
COMPARTMENT LATCH UNLOCKED SWITCH
CONVERTIBLE TOP COMPARTMENT ENCLOSURE CONTROL BUTTON
CONVERTIBLE TOP HYDRAULIC PUMP
CONVERTIBLE TOP LATCH CLOSED SWITCH
CONVERTIBLE TOP LOCK UNIT
FUSE 6
FUSE PANEL 3
FUSE PANEL F
GLOVE COMPARTMENT LOCK MOTOR
GLOVE COMPARTMENT WIRING HARNESS COUPLING POINT
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
LEFT COMPARTMENT LOCKED SWITCH
LEFT COUPLING POINT IN LUGGAGE COMPARTMENT
RED/GRN WIRE
RELAY & FUSE PANEL 2
RIGHT COMPARTMENT LOCKED SWITCH
SWITCH ILLUMINATION BULB
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/RED WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRY WIRE
Go to component -> Convertible top circuit (4 of 4) -> COMPARTMENT COVER LOCKING MOTOR
