Trunk & fuel door release circuit for Audi S5 I facelift (2011-2016)
Trunk & fuel door release circuit
BLU WIRE
BLU/BRN WIRE
BLU/RED WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
COUPE
DRIVER'S DOOR CONTROL MODULE
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S FRONT DOOR)
FUEL FILLER DOOR UNLOCK MOTOR
FUEL TANK LID UNLOCK MOTOR
FUSE 11
FUSE 8
FUSE CARRIER 2
FUSE PANEL C
FUSE PANEL C (LEFT END OF DASH)
FUSE PANEL SC (UNDER LEFT SIDE OF DASH)
GRN/RED WIRE
GRN/YEL WIRE
GROUND DISTRIBUTION SYSTEM
HOT AT ALL TIMES
LEFT LICENSE PLATE LIGHT
ORG/BRN WIRE
ORG/GRN WIRE
REAR LID ALARM SWITCH/REAR LID CENTRAL LOCKING SYSTEM MOTOR
REAR LID LOCK CYLINDER UNLOCK BUTTON
REAR LID REMOTE UNLOCK SWITCH
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RELAY/FUSE PANEL F
RIGHT LICENSE PLATE LIGHT
YEL/GRN WIRE
