Structure borne sound actuator circuit for Audi S5 I facelift (2011-2016)
Structure borne sound actuator circuit
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
FUSE 5
FUSE CARRIER 1
FUSE FUSE CARRIER 1
FUSE PANEL C
FUSE PANEL C (LEFT END OF DASH)
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
ORG/BLK WIRE
ORG/BRN WIRE
STRUCTURE BORNE SOUND ACTUATOR
STRUCTURE BORNE SOUND CONTROL MODULE
