Radio circuit, basic mmi for Audi S5 I facelift (2011-2016)

Radio circuit, basic mmi (1 of 2)

Get access

7 16 18 PIN CONNECTOR (NOT USED) BLU/GRN WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/YEL WIRE CD CHANGER COMPUTER DATA LINES SYSTEM DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT) EXTERNAL AUDIO SOURCE CONNECTION (W/ MMI HIGH) FUSE 1 FUSE 4 FUSE CARRIER 2 FUSE CARRIER 3 FUSE PANEL SD (UNDER RIGHT SIDE OF DASH) GRN/VIO WIRE HOT AT ALL TIMES LEFT FRONT MID-BASS SPEAKER LEFT FRONT TREBLE SPEAKER MOST DATA BUS CIRCUIT NCA WIRE RED/BLK WIRE RED/BLU WIRE RED/VIO WIRE RED/YEL WIRE RELAY/FUSE CARRIER LUGGAGE COMPARTMENT SF (RIGHT SIDE OF LUGGAGE COMPT) RIGHT FRONT MID-BASS SPEAKER RIGHT FRONT TREBLE SPEAKER W/ BASIC W/ HIGH WHT WIRE WHT/GRN WIRE WHT/RED WIRE

Get access

ANTENNA AMPLIFIER 2 ANTENNA AMPLIFIER 3 BLK WIRE BLU/GRN WIRE BRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM FRONT INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE (CENTER OF DASH) FUSE 3 FUSE CARRIER 3 GRN/VIO WIRE HOT AT ALL TIMES LEFT REAR MID/LOW RANGE SPEAKER LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT NCA WIRE RADIO RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA) REAR VIEW CAMERA SYSTEM CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) RED/VIO WIRE RELAY/FUSE CARRIER LUGGAGE COMPT SF (RIGHT SIDE OF LUGGAGE COMPT) RIGHT REAR MID/LOW RANGE SPEAKER RIGHT REAR TREBLE SPEAKER SATELLITE ANTENNA SATELLITE RADIO TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT) TV TUNER (LEFT REAR OF LUGGAGE COMPT) W/ MMI BASIC W/ MMI HIGH W/ REAR VIEW CAMERA SYSTEM W/ SPEAKER PHONE W/O REAR VIEW CAMERA SYSTEM W/O SPEAKER PHONE WHT/GRN WIRE
