Front heated seats circuit, coupe without memory for Audi S5 I facelift (2011-2016)
Front heated seats circuit, coupe without memory
BACKREST HEATER
BACKREST HEATING ELEMENT
BACKREST SEAT BOLSTER HEATER
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CLIMATRONIC CONTROL MODULE (BEHIND CENTER OF DASH)
COMPUTER DATA LINES SYSTEM
DRIVER'S BACKREST HEATING ELEMENT
DRIVER'S SEAT HEATER LEFT FRONT SEAT TEMP SENSOR
FRONT PASSENGER'S
FRONT PASSENGER'S SEAT HEATER
FUSE
FUSE CARRIER 2
FUSE PANEL C (LEFT END OF DASH)
GRN WIRE
GRN/BRN WIRE
HEATED DRIVER SEAT ADJUSTER
HEATED FRONT PASSENGER SEAT ADJUSTER
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT FRONT SEAT TEMP SENSOR
SEAT BOLSTER HEATER
SEAT BOLSTER HEATER (IF EQUIPPED)
SEAT HEATER
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
YEL/BLU WIRE
