Audi S5 I facelift (2011-2016) w/ music interface Wiring diagrams
This page contains all the electrical diagrams for the component. w/ music interface, in which he is found in the car Audi S5 I facelift (2011-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram w/ music interface (1 of 8)
18 PIN CONNECTOR
18-PIN CONNECTOR (NOT USED)
ANTENNA AMPLIFIER 2
ANTENNA AMPLIFIER 3
ANTENNA AMPLIFIER 4
ANTENNA AMPLIFIER 4 (CONVERTIBLE) (LEFT CENTER OF TOP STORAGE COMPT LID)
BLK WIRE
BLK/RED WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COUPE
DIGITAL RADIO ANTENNA
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 1
FUSE 3
FUSE CARRIER 2
FUSE PANEL D
FUSE PANEL D (RIGHT END OF DASH)
FUSE PANEL SD (UNDER RIGHT SIDE OF DASH)
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RADIO
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA) SATELLITE ANTENNA
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
SATELLITE ANTENNA
TELEPHONE TRANSCEIVER
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
W/ MUSIC INTERFACE
W/ SPEAKER PHONE
W/O MUSIC INTERFACE
W/O SPEAKER PHONE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, basic infotainment (1 of 2) -> W/ MUSIC INTERFACE
Wiring diagram w/ music interface (2 of 8)
18 PIN CONNECTOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
EXTERNAL AUDIO SOURCE CONNECTION
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
INTERIOR MICROPHONE
LEFT FRONT MICROPHONE MICROPHONE UNIT
LEFT FRONT MICROPHONE MICROPHONE UNIT (IN FRONT ROOF MODULE)
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID- BASS SPEAKER
RIGHT REAR TREBLE SPEAKER
SATELLITE ANTENNA
TELEPHONE TRANSCEIVER
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
W/ MUSIC INTERFACE
W/ SPEAKER PHONE
W/O MUSIC INTERFACE
W/O SPEAKER PHONE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, convertible premium infotainment (2 of 3) -> W/ MUSIC INTERFACE
Wiring diagram w/ music interface (3 of 8)
18 PIN CONNECTOR
18-PIN CONNECTOR (NOT USED)
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER 2
ANTENNA AMPLIFIER 3
BLK WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 1
FUSE 3
FUSE CARRIER 2
FUSE PANEL D
FUSE PANEL D (RIGHT END OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RADIO
RADIO, TELEPHONE NAVIGATION
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA
RED/GRN WIRE
RED/GRY WIRE
SYSTEM ANTENNA (W/ ROOF ANTENNA)
TELEPHONE TRANSCEIVER
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
W/ MUSIC INTERFACE
W/ SPEAKER PHONE
W/O MUSIC INTERFACE
W/O SPEAKER PHONE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, coupe premium infotainment (1 of 2) -> W/ MUSIC INTERFACE
Wiring diagram w/ music interface (4 of 8)
18 PIN CONNECTOR
18-PIN CONNECTOR (NOT USED)
ANTENNA AMPLIFIER 2
ANTENNA AMPLIFIER 3
ANTENNA AMPLIFIER 4
ANTENNA AMPLIFIER 4 (CONVERTIBLE) (LEFT CENTER OF TOP
BLK WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
COUPE
DIGITAL RADIO ANTENNA
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 1
FUSE 3
FUSE 4
FUSE CARRIER 2
FUSE CARRIER 2 FUSE 1
FUSE CARRIER 3
FUSE CARRIER 3 FUSE 4
FUSE PANEL D
FUSE PANEL D (RIGHT END OF DASH)
FUSE PANEL SD (UNDER RIGHT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RADIO
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA)
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA) SATELLITE ANTENNA
RED/GRN WIRE
RED/GRY WIRE
RELAY/ FUSE PANEL F
RELAY/ FUSE PANEL F (RIGHT SIDE OF LUGGAGE COMPT)
SATELLITE ANTENNA
STORAGE COMPT LID)
TELEPHONE TRANSCEIVER
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
W/ MUSIC INTERFACE
W/ SPEAKER PHONE
W/O MUSIC INTERFACE
W/O SPEAKER PHONE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Navigation circuit, standard infotainment (1 of 2) -> W/ MUSIC INTERFACE
Wiring diagram w/ music interface (5 of 8)
18 PIN CONNECTOR
18-PIN CONNECTOR (NOT USED)
ANTENNA AMPLIFIER 2
ANTENNA AMPLIFIER 3
ANTENNA AMPLIFIER 4
ANTENNA AMPLIFIER 4 (CONVERTIBLE) (LEFT CENTER OF TOP STORAGE COMPT LID)
BLK WIRE
BLK/RED WIRE
BLU/GRN WIRE
BRN WIRE
BRN/BLU WIRE
BRN/VIO WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COUPE
DIGITAL RADIO ANTENNA
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 1
FUSE 3
FUSE CARRIER 2
FUSE PANEL D
FUSE PANEL D (RIGHT END OF DASH)
FUSE PANEL SD (UNDER RIGHT SIDE OF DASH)
GRN WIRE
GRN/BLU WIRE
GRY WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RADIO
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA) SATELLITE ANTENNA
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
SATELLITE ANTENNA
TELEPHONE TRANSCEIVER
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
W/ MUSIC INTERFACE
W/ SPEAKER PHONE
W/O MUSIC INTERFACE
W/O SPEAKER PHONE
WHT WIRE
WHT/BLU WIRE
WHT/GRN WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Radio circuit, basic infotainment (1 of 2) -> W/ MUSIC INTERFACE
Wiring diagram w/ music interface (6 of 8)
18 PIN CONNECTOR
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/GRN WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL RADIO ANTENNA
EXTERNAL AUDIO SOURCE CONNECTION
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
INTERIOR MICROPHONE
LEFT FRONT MICROPHONE MICROPHONE UNIT
LEFT FRONT MICROPHONE MICROPHONE UNIT (IN FRONT ROOF MODULE)
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
RIGHT FRONT BASS SPEAKER
RIGHT FRONT TREBLE SPEAKER
RIGHT REAR MID- BASS SPEAKER
RIGHT REAR TREBLE SPEAKER
SATELLITE ANTENNA
TELEPHONE TRANSCEIVER
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
W/ MUSIC INTERFACE
W/ SPEAKER PHONE
W/O MUSIC INTERFACE
W/O SPEAKER PHONE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Radio circuit, convertible premium infotainment (2 of 3) -> W/ MUSIC INTERFACE
Wiring diagram w/ music interface (7 of 8)
18 PIN CONNECTOR
18-PIN CONNECTOR (NOT USED)
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER 2
ANTENNA AMPLIFIER 3
BLK WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 1
FUSE 3
FUSE CARRIER 2
FUSE PANEL D
FUSE PANEL D (RIGHT END OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RADIO
RADIO, TELEPHONE NAVIGATION
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA
RED/GRN WIRE
RED/GRY WIRE
SYSTEM ANTENNA (W/ ROOF ANTENNA)
TELEPHONE TRANSCEIVER
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
W/ MUSIC INTERFACE
W/ SPEAKER PHONE
W/O MUSIC INTERFACE
W/O SPEAKER PHONE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Radio circuit, coupe premium infotainment (1 of 2) -> W/ MUSIC INTERFACE
Wiring diagram w/ music interface (8 of 8)
18 PIN CONNECTOR
18-PIN CONNECTOR (NOT USED)
ANTENNA AMPLIFIER 2
ANTENNA AMPLIFIER 3
ANTENNA AMPLIFIER 4
ANTENNA AMPLIFIER 4 (CONVERTIBLE) (LEFT CENTER OF TOP
BLK WIRE
BRN WIRE
BRN/BLU WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
COUPE
DIGITAL RADIO ANTENNA
EXTERNAL AUDIO SOURCE CONNECTION
FUSE 1
FUSE 3
FUSE 4
FUSE CARRIER 2
FUSE CARRIER 2 FUSE 1
FUSE CARRIER 3
FUSE CARRIER 3 FUSE 4
FUSE PANEL D
FUSE PANEL D (RIGHT END OF DASH)
FUSE PANEL SD (UNDER RIGHT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/VIO WIRE
RADIO
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA)
RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA) SATELLITE ANTENNA
RED/GRN WIRE
RED/GRY WIRE
RELAY/ FUSE PANEL F
RELAY/ FUSE PANEL F (RIGHT SIDE OF LUGGAGE COMPT)
SATELLITE ANTENNA
STORAGE COMPT LID)
TELEPHONE TRANSCEIVER
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
W/ MUSIC INTERFACE
W/ SPEAKER PHONE
W/O MUSIC INTERFACE
W/O SPEAKER PHONE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/RED WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Radio circuit, standard infotainment (1 of 2) -> W/ MUSIC INTERFACE
