Audi S5 I facelift (2011-2016) humidity sensor Wiring diagrams
This page contains all the electrical diagrams for the component. humidity sensor, in which he is found in the car Audi S5 I facelift (2011-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram humidity sensor (1 of 2)
A/C PRESSURE/ TEMPERATURE SENSOR
A/C PRESSURE/ TEMPERATURE SENSOR (ON A/C HIGH PRESSURE LINE)
AIR QUALITY SENSOR
AUTOMATIC DAY/ NIGHT INTERIOR MIRROR
BLK/BLU WIRE
BLK/RED WIRE
BLU/BRN WIRE
BLU/RED WIRE
BLU/WHT WIRE
BRN WIRE
BRN/BLK WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
COUPE
ENGINE COOLANT LEVEL (ECL) SENSOR
ENGINE COOLANT LEVEL (ECL) SENSOR (IN COOLANT RESERVOIR)
EVAPORATOR VENT TEMPERATURE SENSOR
EVAPORATOR VENT TEMPERATURE SENSOR (RIGHT SIDE OF A/C UNIT)
FRESH AIR BLOWER
FRESH AIR BLOWER (UNDER AIR INTAKE HOUSING)
FRESH AIR BLOWER CONTROL MODULE
FRESH AIR BLOWER CONTROL MODULE (UNDER RIGHT SIDE OF DASH)
FUSE
FUSE 12
FUSE 3
FUSE CARRIER 1
FUSE CARRIER 1 FUSE
FUSE CARRIER 2
FUSE PANEL SC
FUSE PANEL SC (LEFT END OF DASH)
FUSE PANEL SC (UNDER LEFT SIDE OF DASH)
GRN/BLU WIRE
GRN/BRN WIRE
GRN/VIO WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERM 15) ENERGIZED
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
HUMIDITY SENSOR
HUMIDITY, RAIN/LIGHT RECOGNITION SENSOR
INTERIOR REARVIEW MIRROR
LEFT FOOTWELL VENT TEMPERATURE SENSOR
LEFT FOOTWELL VENT TEMPERATURE SENSOR (LEFT SIDE OF A/C UNIT)
LEFT FRONT UPPER BODY OUTLET TEMPERATURE SENSOR
LEFT FRONT UPPER BODY VENT TEMPERATURE SENSOR
MIRRORS SYSTEM
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
OUTSIDE AIR TEMPERATURE SENSOR
RED/BLU WIRE
RED/WHT WIRE
RIGHT FOOTWELL VENT TEMPERATURE SENSOR
RIGHT FOOTWELL VENT TEMPERATURE SENSOR (LOWER RIGHT SIDE OF A/C UNIT)
RIGHT FRONT UPPER BODY OUTLET TEMPERATURE SENSOR (BEHIND RIGHT SIDE OF DASH)
RIGHT FRONT UPPER BODY VENT TEMPERATURE SENSOR
RIGHT FRONT UPPER BODY VENT TEMPERATURE SENSOR (BEHIND RIGHT SIDE OF DASH)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (ON RELAY & FUSE PANEL)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
VIO WIRE
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BLK WIRE
WHT/BRN WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Automatic a/c circuit, comfort (2 of 3) -> HUMIDITY SENSOR
Wiring diagram humidity sensor (2 of 2)
AUTOMATIC DAY/NIGHT INTERIOR MIRROR
BLK WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DAY/NIGHT
DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S DOOR)
FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S DOOR)
FUSE
FUSE CARRIER 1
FUSE CARRIER 2 FUSE
FUSE CARRIER 3
FUSE PANEL SC (UNDER LEFT SIDE OF DASH)
HOT AT ALL TIMES
HUMIDITY SENSOR
LIGHT RECOG- NITION SENSOR
ORG/BRN WIRE
ORG/GRN WIRE
ORG/GRY WIRE
RED/WHT WIRE
RED/YEL WIRE
VIO WIRE
VIO/WHT WIRE
VIO/YEL WIRE
W/ AUTOMATIC HIGH BEAM CONTROL
W/O AUTOMATIC HIGH BEAM CONTROL
WHT/BLU WIRE
Go to component -> Automatic day/night mirror circuit, with humidity sensor -> HUMIDITY SENSOR
