Audi S5 I facelift (2011-2016) high mount brake light Wiring diagrams

This page contains all the electrical diagrams for the component. high mount brake light, in which he is found in the car Audi S5 I facelift (2011-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram high mount brake light (1 of 3)

Wiring diagram high mount brake light for Audi S5 I facelift (2011-2016) (1 of 3)

Get lifetime access to Audi S5 I facelift (2011-2016)

4.2L 3.0L BACKUP BACKUP 2 BACKUP LAMPS CIRCUIT BLK WIRE BLK/GRN WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRAKE LIGHT SWITCH (ON BRAKE PEDAL ASSEMBLY) BRAKE/ BRAKE/ TURN BRAKE/ TURN/TAIL BRAKE/TURN/ TAIL BRAKE/TURN/ TAIL 2 BRN WIRE CLIMATRONIC CONTROL MODULE CLUTCH POSITION SENSOR (M/T) COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER) FUSE 2 FUSE FUSE CARRIER 2 PANEL SC (UNDER LEFT SIDE OF DASH) GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/WHT WIRE GRY/YEL WIRE HIGH MOUNT BRAKE LIGHT LEFT LICENSE PLATE LIGHT LEFT TAILLAMP ASSEMBLY 1 LEFT TAILLAMP ASSEMBLY 2 MARKER REAR LID LOCK CYLINDER UNLOCK BUTTON RED WIRE RED/BLK WIRE RED/GRY WIRE RIGHT LICENSE PLATE LIGHT RIGHT TAILLAMP ASSEMBLY 1 RIGHT TAILLAMP ASSEMBLY 2 TRUNK LID ALARM SWITCH TURN TURN/TAIL BRAKE/ WHT WIRE YEL WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> Exterior lamps circuit (2 of 2) -> HIGH MOUNT BRAKE LIGHT

Wiring diagram high mount brake light (2 of 3)

Wiring diagram high mount brake light for Audi S5 I facelift (2011-2016) (2 of 3)

Get lifetime access to Audi S5 I facelift (2011-2016)

BACKUP LAMP 2 BACKUP LAMPS CIRCUIT BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BLU/RED WIRE BRAKE/ TURN SIGNAL LAMP 4 BRAKE/TURN SIGNAL LAMP 4 BRN WIRE CLUTCH POSITION SENSOR CLUTCH POSITION SENSOR (M/T) (TOP OF CLUTCH PEDAL ASSEMBLY) COMFORT SYSTEM CENTRAL CONTROL MODULE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM COUPE FOG LAMP FRONT DRL TURN LAMP SIGNAL LAMP FRONT TURN SIGNAL LAMP GRN WIRE GRN/BLU WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE GRY/WHT WIRE GRY/YEL WIRE HIGH MOUNT BRAKE LIGHT HIGH-MOUNTED BRAKE LIGHT LEFT REAR TAILLAMP ASSEMBLY 2 LEFT REAR TAILLAMP ASSEMBLY 2 (W/ LED REAR LIGHTS) LEFT REAR TAILLAMP ASSEMBLY 2 (W/O LED REAR LIGHTS) M/T ORG/BRN WIRE ORG/GRN WIRE PARKING/ FOG LAMP REAR LID LOCK/ ALARM/CENTRAL LOCKING SWITCH REAR LID LOCK/ ALRAM/CENTRAL CONTROL MODULE RED/BLK WIRE RIGHT DRL, PARKING LAMP CONTROL MODULE RIGHT DRL, PARKING LAMP CONTROL MODULE (IF EQUIPPED) RIGHT FRONT HEADLAMP RIGHT FRONT SIDE MARKER LAMP BULB RIGHT FRONT TURN RIGHT HEADLIGHT ASSEMBLY RIGHT POSITION LAMP RIGHT SIDE MARKER LAMP POWER OUTPUT STAGE SIGNAL BULB TAIL LAMP 2 VALET PARKING IND LAMP VALET PARKING LOCK BUTTON W/ BI-XENON W/ LED REAR LIGHTS W/O BI-XENON YEL WIRE YEL/GRN WIRE YEL/RED WIRE

Go to component -> Exterior lamps circuit (2 of 3) -> HIGH MOUNT BRAKE LIGHT
