Audi S5 I facelift (2011-2016) heated front passenger Wiring diagrams

This page contains all the electrical diagrams for the component. heated front passenger, in which he is found in the car Audi S5 I facelift (2011-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

Wiring diagram heated front passenger (1 of 3)

Wiring diagram heated front passenger for Audi S5 I facelift (2011-2016) (1 of 3)

Get lifetime access to Audi S5 I facelift (2011-2016)

BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE CLIMATRONIC CONTROL MODULE (BEHIND CENTER OF DASH) COMPUTER DATA LINES SYSTEM DRIVER'S BACKREST SEAT BACKREST HEATING ELEMENT HEATER DRIVER'S SEAT BACKREST BLOWER FAN (IN DRIVER'S FRONT SEAT BACK) DRIVER'S SEAT BACKREST BLOWER FAN 2 (IN DRIVER'S FRONT SEAT BACK) DRIVER'S SEAT CUSHION BLOWER FAN (IN DRIVER'S FRONT SEAT CUSHION) DRIVER'S SEAT CUSHION BLOWER FAN 2 (IN DRIVER'S FRONT SEAT CUSHION) DRIVER'S SEAT HEATER ELEMENT FRONT PASSENGER'S BACKREST HEATING FRONT PASSENGER'S SEAT BACKREST BLOWER FAN (IN PASSENGER'S FRONT SEAT BACK) FRONT PASSENGER'S SEAT BACKREST BLOWER FAN 2 (IN PASSENGER'S FRONT SEAT BACK) FRONT PASSENGER'S SEAT CUSHION BLOWER FAN (IN PASSENGER'S FRONT SEAT CUSHION) FRONT PASSENGER'S SEAT CUSHION BLOWER FAN 2 (IN PASSENGER'S FRONT SEAT CUSHION) FRONT PASSENGER'S SEAT HEATER RIGHT FRONT SEAT TEMP SENSOR GRN WIRE HEATED DRIVER SEAT ADJUSTER HEATED FRONT PASSENGER HEATER HOT AT ALL TIMES LEFT FRONT SEAT BOLSTER HEATER SEAT TEMP SENSOR MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE (UNDER DRIVER'S SEAT) ORG/BRN WIRE ORG/GRN WIRE PASSENGER MEMORY SEAT CONTROL MODULE (UNDER FRONT PASSENGER'S SEAT) RED WIRE RED/BLK WIRE RED/YEL WIRE SEAT ADJUSTER SEAT BACKREST HEATER SEAT BOLSTER SEAT BOLSTER HEATER SEAT HEATER YEL WIRE

Go to component -> Front heated seats circuit, convertible with memory -> HEATED FRONT PASSENGER

Wiring diagram heated front passenger (2 of 3)

Wiring diagram heated front passenger for Audi S5 I facelift (2011-2016) (2 of 3)

Get lifetime access to Audi S5 I facelift (2011-2016)

BLK WIRE BLK/GRN WIRE BLK/WHT WIRE BLU WIRE BRN WIRE BRN/YEL WIRE CLIMATRONIC CONTROL MODULE (BEHIND CENTER OF DASH) COMPUTER DATA LINES SYSTEM DRIVER'S BACKREST HEATING ELEMENT DRIVER'S SEAT HEATING ELEMENT DRIVER'S SEAT HEATING ELEMENT LEFT FRONT SEAT TEMP SENSOR FRONT PASSENGER'S BACKREST HEATING ELEMENT FRONT PASSENGER'S SEAT HEATER FUSE FUSE 6 FUSE CARRIER 1 FUSE FUSE CARRIER 2 FUSE FUSE CARRIER 3 FUSE PANEL C (LEFT END OF DASH) GRN WIRE GRN/BRN WIRE GRY/BLK WIRE GRY/WHT WIRE HEATED DRIVER SEAT ADJUSTER HEATED FRONT PASSENGER HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED LEFT HEAD AREA HEATER CONTROL MODULE LEFT HEAD AREA HEATER FAN LEFT HEAD AREA HEATER RELAY LEFT HEAD AREA HEATER SWITCH NCA WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/GRN WIRE RED/GRY WIRE RELAY/ FUSE PANEL F (RIGHT SIDE OF LUGGAGE COMPT) RIGHT FRONT SEAT TEMP SENSOR RIGHT HEAD AREA HEATER CONTROL MODULE RIGHT HEAD AREA HEATER FAN RIGHT HEAD AREA HEATER RELAY RIGHT HEAD AREA HEATER SWITCH SEAT ADJUSTER SEAT HEATING ELEMENT VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) VIO/WHT WIRE WHT WIRE YEL WIRE YEL/BLU WIRE YEL/GRY WIRE

Go to component -> Front heated seats circuit, convertible without memory -> HEATED FRONT PASSENGER
