Audi S5 I facelift (2011-2016) brn Wiring diagrams

This page contains all the electrical diagrams for the component. brn, in which he is found in the car Audi S5 I facelift (2011-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..

brn wiring diagram (111 of 184)

Audi S5 I facelift (2011-2016) brn wiring diagram (111 of 184)

2.0L TURBO 3 4 COMPUTER DATA LINES SYSTEM 3.0L EXCEPT 3.0L BATTERY BATTERY INTERRUPT IGNITER BATTERY JUMP START TERMINAL BATTERY JUMP START TERMINAL (ON TERMINAL 30 WIRE JUNCTION BLOCK) BATTERY MONITORING CONTROL MODULE BATTERY MONITORING CONTROL MODULE (AT BATTERY) BATTERY MONITORING CONTROL MODULE (ON NEGATIVE POST OF BATTERY) BLK WIRE BLU WIRE BRN WIRE DATA BUS ON BOARD DIAGNOSTIC INTERFACE DATA BUS ON BOARD DIAGNOSTIC INTERFACE (ABOVE GLOVE BOX) DATA BUS ON BOARD DIAGNOSTIC INTERFACE (RIGHT CENTER OF DASH) ENGINE CONTROLS SYSTEM EXCEPT 2.0L TURBO FUSE PANEL A (ON BATTERY, IN LUGGAGE COMPT) FUSE PANEL SA GENERATOR, VOLTAGE REGULATOR INSTRUMENT CLUSTER CONTROL MODULE MAIN FUSE PANEL SA (ON BATTERY, IN LUGGAGE COMPT) ORG/BLU WIRE ORG/BRN WIRE RED WIRE RED/BRN WIRE STARTER SUPPLEMENTAL RESTRAINTS SYSTEM SUPPRESSOR TERMINAL 30 WIRE JUNCTION 2 (MIDDLE OF PLENUM CHAMBER IN ENGINE COMPT) VIO WIRE VIO/BLU WIRE VOLTAGE STABILIZER VOLTAGE STABILIZER (W/ START/STOP SYSTEM) (NEAR BATTERY) W/ START/ STOP SYSTEM WHT WIRE

Go to component -> Charging circuit -> BRN WIRE

brn wiring diagram (112 of 184)

Audi S5 I facelift (2011-2016) brn wiring diagram (112 of 184)

ABS CONTROL MODULE ABS CONTROL MODULE (LEFT REAR OF ENGINE COMPT) ABS CONTROL MODULE (LEFT SIDE OF ENGINE COMPT) AUTO HOLD BUTTON BLK WIRE BLK/YEL WIRE BLU/GRN WIRE BLU/RED WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/WHT WIRE BRN/YEL WIRE CARRIER LUGGAGE COMPT SF (RIGHT SIDE OF LUGGAGE CLUTCH POSITION SENSOR CLUTCH POSITION SENSOR (M/T) CLUTCH POSITION SENSOR (M/T) (TOP OF CLUTCH PEDAL ASSEMBLY) COMPT) COMPUTER DATA LINES SYSTEM ELECTRO- MECHANICAL PARKING BRAKE BUTTON ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE ELECTRO-MECHANICAL PARKING BRAKE CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) FUSE FUSE 3 FUSE 5 FUSE 7 FUSE 8 FUSE CARRIER 1 FUSE CARRIER 1 FUSE FUSE CARRIER 2 FUSE CARRIER 3 FUSE CARRIER 4 FUSE PANEL FUSE PANEL SC FUSE PANEL SF GRN/RED WIRE GRY/BLU WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED HOT W/ POWER SUPPLY RELAY 15 ENERGIZED HOT W/ POWER SUPPLY RELAY ENERGIZED LEFT PARKING BRAKE MOTOR LEFT PARKING BRAKE MOTOR (ON LEFT REAR BRAKE CALIPER ASSEMBLY) M/T ORG/BLU WIRE ORG/BRN WIRE RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE RED/YEL WIRE RELAY/ FUSE RELAY/FUSE PANEL F (RIGHT SIDE OF LUGGAGE COMPT) RIGHT PARKING BRAKE MOTOR RIGHT PARKING BRAKE MOTOR (ON RIGHT REAR BRAKE CALIPER ASSEMBLY) SC (LEFT END OF DASH) VIO/GRY WIRE WHT/BLK WIRE WHT/VIO WIRE

Go to component -> Park brake release circuit -> BRN WIRE

brn wiring diagram (113 of 184)

Audi S5 I facelift (2011-2016) brn wiring diagram (113 of 184)

18 PIN CONNECTOR 18-PIN CONNECTOR (NOT USED) ANTENNA AMPLIFIER 2 ANTENNA AMPLIFIER 3 ANTENNA AMPLIFIER 4 ANTENNA AMPLIFIER 4 (CONVERTIBLE) (LEFT CENTER OF TOP BLK WIRE BRN WIRE BRN/BLU WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM COUPE DIGITAL RADIO ANTENNA EXTERNAL AUDIO SOURCE CONNECTION FUSE 1 FUSE 3 FUSE 4 FUSE CARRIER 2 FUSE CARRIER 2 FUSE 1 FUSE CARRIER 3 FUSE CARRIER 3 FUSE 4 FUSE PANEL D FUSE PANEL D (RIGHT END OF DASH) FUSE PANEL SD (UNDER RIGHT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES NCA WIRE ORG/BRN WIRE ORG/VIO WIRE RADIO RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA) RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA (W/ ROOF ANTENNA) SATELLITE ANTENNA RED/GRN WIRE RED/GRY WIRE RELAY/ FUSE PANEL F RELAY/ FUSE PANEL F (RIGHT SIDE OF LUGGAGE COMPT) SATELLITE ANTENNA STORAGE COMPT LID) TELEPHONE TRANSCEIVER TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT) W/ MUSIC INTERFACE W/ SPEAKER PHONE W/O MUSIC INTERFACE W/O SPEAKER PHONE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE YEL/RED WIRE

Go to component -> Radio circuit, standard infotainment (1 of 2) -> BRN WIRE

brn wiring diagram (114 of 184)

Audi S5 I facelift (2011-2016) brn wiring diagram (114 of 184)

ANTENNA AMPLIFIER ANTENNA AMPLIFIER 2 BLK WIRE BLK/WHT WIRE BLU WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/GRY WIRE BRN/VIO WIRE BRN/YEL WIRE CENTER MID- TREBLE SPEAKER CENTER MID/HIGH RANGE SPEAKER COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DIGITAL SOUND SYSTEM CONTROL MODULE DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF DIGITAL SOUND SYSTEM CONTROL MODULE (LEFT REAR OF LUGGAGE COMPT) FRONT INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE FRONT INFORMATION DISPLAY CONTROL HEAD CONTROL MODULE (CENTER OF DASH) FUSE 4 FUSE CARRIER 3 GPS ANTENNA GRN WIRE GRN/BLK WIRE GRN/BLU WIRE GRN/VIO WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT ANTENNA MODULE LEFT FRONT MID-BASS SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR MID-BASS SPEAKER LEFT REAR MID/LOW RANGE SPEAKER LEFT REAR RIGHT REAR MID-BASS TREBLE SPEAKER SPEAKER LEFT REAR TREBLE SPEAKER LUGGAGE COMPT) NCA WIRE ORG/BRN WIRE ORG/VIO WIRE PNK WIRE RADIO RADIO, TV ANTENNA RED WIRE RED/BLU WIRE RED/GRY WIRE RED/VIO WIRE RED/YEL WIRE RELAY/ FUSE CARRIER LUGGAGE COMPT SF (RIGHT SIDE OF RIGHT FRONT MID-BASS SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR MID- BASS SPEAKER RIGHT REAR MID/LOW RANGE SPEAKER RIGHT REAR TREBLE SPEAKER SUBWOOFER SUBWOOFER (IF EQUIPPED) VIO WIRE WHT WIRE WHT/BLK WIRE WHT/BLU WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL WIRE

Go to component -> Radio circuit, standard infotainment (2 of 2) -> BRN WIRE

brn wiring diagram (115 of 184)

Audi S5 I facelift (2011-2016) brn wiring diagram (115 of 184)

2.0L TURBO 2.0L TURBO 3.0L 3.2L 4.2L A/C CONTROL HEAD CLIMATRONIC CONTROL MODULE (BEHIND CENTER OF DASH) A/T CVT ACCESS/START AUTHORIZATION BUTTON ACCESS/START AUTHORIZATION SWITCH BLK WIRE BLK/BRN WIRE BLU WIRE BLU/GRY WIRE BRAKE LIGHT SWITCH BRAKE LIGHT SWITCH (ON BRAKE PEDAL ASSEMBLY) BRN WIRE CLIMATE CONTROL MODULE COMFORT SYSTEM CENTRAL CONTROL MODULE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM CONVER- TIBLE COUPE COUPE CONVERTIBLE DIRECT SHIFT GEARBOX (DSG) MECHATRONIC ENGINE CONTROL MODULE (ECM) ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER) FRONT INTERIOR LAMP FUSE FUSE 10 FUSE CARRIER 1 FUSE PANEL SC FUSE PANEL SC (LEFT END OF DASH) FUSE PANEL SC (UNDER LEFT SIDE OF DASH) GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/WHT WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED INTERIOR LIGHTING SWITCH ORG/BLK WIRE ORG/BRN WIRE PRNDS RED WIRE RED/BLK WIRE RED/BRN WIRE SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ATTACHED TO SHIFT LEVER ASSEMBLY) SHIFT LOCK SOLENOID TRANSMISSION CONTROL MODULE (TCM) TRANSMISSION CONTROL MODULE (TCM) (UNDER TRANSMISSION OIL PAN) TRANSMISSION CONTROL MODULE (TCM) DIRECT SHIFT GEARBOX (DSG) MECHATRONIC VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (ON RELAY & FUSE PANEL) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) W/ DIRECT SHIFT W/ MULTITRONIC W/O MULTITRONIC W/O DIRECT SHIFT

Go to component -> Shift interlock circuit -> BRN WIRE

brn wiring diagram (116 of 184)

Audi S5 I facelift (2011-2016) brn wiring diagram (116 of 184)

2.0L TURBO 8 SPEED A/T ACCESS/START AUTHORIZATION BUTTON (UNDER TRANSMISSION OIL PAN) (CONVERTIBLE) BATTERY BATTERY INTERRUPT IGNITER BLK WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CHARGING CIRCUIT COMPUTER DATA LINES SYSTEM COUPE CVT DIRECT SHIFT GEARBOX (DSG) TRANSMISSION MECHATRONIC (IN TRANSMISSION HOUSING) EXCEPT 2.0L TURBO FUSE FUSE 2 FUSE CARRIER FUSE PANEL A (ON BATTERY, IN LUGGAGE COMPT) GRN/VIO WIRE GRY WIRE GRY/BLK WIRE GRY/WHT WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RELAY/ FUSE PANEL B (IN LEFT PLENUM CHAMBER E-BOX) SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ATTACHED TO SHIFT LEVER ASSEMBLY) START/STOP MODE BUTTON (IF EQUIPPED) STARTER SUPPLEMENTAL RESTRAINTS SYSTEM TERMINAL 30 WIRE JUNCTION 2 (MIDDLE OF PLENUM CHAMBER IN ENGINE COMPT) TRANSMISSION CONTROL MODULE (TCM) TRANSMISSION PARK SELECTOR SWITCH (INTEGRAL TO SHIFT LOCK SOLENOID ASSEMBLY) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) W/ DIRECT SHIFT GEARBOX

Go to component -> Starting circuit (1 of 2) -> BRN WIRE

brn wiring diagram (117 of 184)

Audi S5 I facelift (2011-2016) brn wiring diagram (117 of 184)

2.0L TURBO 4.2L BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLU/GRY WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CLUTCH POSITION SENSOR (M/T) (TOP OF CLUTCH PEDAL ASSEMBLY) COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER) ENGINE CONTROLS SYSTEM FUSE FUSE CARRIER 1 FUSE FUSE CARRIER 1 FUSE 10 FUSE CARRIER 2 FUSE FUSE PANEL C GRN/GRY WIRE HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE POWER SUPPLY RELAY (TERMINAL 15) (ON RELAY PANEL W/ VEHICLE ELECTRICAL RED WIRE RED/BLK WIRE RELAY/ FUSE PANEL B (IN LEFT PLENUM CHAMBER E-BOX) STARTER RELAY (ON RELAY/FUSE PANEL B) STARTER RELAY 2 (ON RELAY/FUSE PANEL B) SYSTEM CONTROL MODULE) VIO/GRY WIRE VOLTAGE STABILIZER (W/ START/STOP SYSTEM) (NEAR BATTERY) W/ START/STOP SYSTEM W/O START/STOP SYSTEM

Go to component -> Starting circuit (2 of 2) -> BRN WIRE

brn wiring diagram (118 of 184)

Audi S5 I facelift (2011-2016) brn wiring diagram (118 of 184)

ACCESS/START AUTHORIZATION BUTTON ACCESS/START AUTHORIZATION SWITCH BRN WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT) ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE (BEHIND LEFT SIDE OF DASH) ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE (ON STEERING COLUMN) FUSE FUSE 9 FUSE CARRIER 2 FUSE PANEL SD FUSE PANEL SD (RIGHT END OF DASH) FUSE PANEL SD (UNDER RIGHT SIDE OF DASH) GRY/BLK WIRE HOT AT ALL TIMES RED WIRE RED/BLU WIRE RED/VIO WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (ON RELAY & FUSE PANEL) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH) VIO WIRE VIO/BLU WIRE WHT/BLK WIRE

Go to component -> Steering column circuit -> BRN WIRE

brn wiring diagram (119 of 184)

Audi S5 I facelift (2011-2016) brn wiring diagram (119 of 184)

BLK WIRE BLK/BLU WIRE BLU WIRE BRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM FUSE 5 FUSE CARRIER 1 FUSE FUSE CARRIER 1 FUSE PANEL C FUSE PANEL C (LEFT END OF DASH) HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED ORG/BLK WIRE ORG/BRN WIRE STRUCTURE BORNE SOUND ACTUATOR STRUCTURE BORNE SOUND CONTROL MODULE

Go to component -> Structure borne sound actuator circuit -> BRN WIRE

brn wiring diagram (120 of 184)

Audi S5 I facelift (2011-2016) brn wiring diagram (120 of 184)

AIR BAG CONTROL MODULE AIR BAG CONTROL MODULE (UNDER CENTER CONSOLE) AIR BAG SPIRAL SPRING/ RETURN SPRING AIR BAG SPIRAL SPRING/ RETURN SPRING (W/ SLIP RING) BATTERY INTERRUPT IGNITER BLK WIRE BLK/BRN WIRE BLK/WHT WIRE BLU WIRE BLU/BLK WIRE BLU/WHT WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S AIR BAG IGNITER DRIVER'S AIR BAG IGNITER (IN STEERING WHEEL) IGNITER 2 DRIVER'S FRONT AIR BAG CRASH SENSOR (ON DRIVER HEADLAMP HOUSING BRACKET) DRIVER'S FRONT AIR- BAG CRASH SENSOR DRIVER'S SIDE AIR BAG CRASH SENSOR (IN DRIVER'S DOOR) DRIVER'S SIDE AIR- BAG CRASH SENSOR DRIVER'S SIDE REAR AIR BAG CRASH SENSOR DRIVER'S SIDE REAR SIDE AIR BAG CRASH SENSOR (BEHIND DRIVER REAR QUARTERPANEL) FRONT PASSENGER'S AIR BAG DISABLED INDICATOR LAMP FRONT PASSENGER'S FRONT AIR BAG CRASH SENSOR FRONT PASSENGER'S SIDE AIR BAG CRASH SENSOR FRONT PASSENGER'S SIDE AIR BAG CRASH SENSOR (IN FRONT PASSENGER'S DOOR) FRONT PASSENGER'S SIDE REAR AIR BAG CRASH SENSOR FUSE 13 FUSE CARRIER 1 FUSE CARRIER FUSE 12 FUSE FUSE 13 CARRIER FUSE PANEL A FUSE PANEL A (ON BATTERY, IN LUGGAGE COMPT) FUSE PANEL C FUSE PANEL C (LEFT END OF DASH) GRN WIRE GRY WIRE GRY/RED WIRE HOT AT ALL TIMES HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED IGNITER IGNITER 2 MAIN FUSE PANEL SA (ON BATTERY, IN LUGGAGE COMPT) NCA WIRE ORG/BLK WIRE ORG/BRN WIRE POWER DISTRIBUTION SYSTEM RED WIRE RED/BLK WIRE RELAY/ FUSE CARRIER LUGGAGE COMPARTMENT SF (RIGHT SIDE OF LUGGAGE COMPT) SOLID STATE VIO WIRE WHT WIRE WHT/VIO WIRE YEL WIRE YEL/GRY WIRE

Go to component -> Supplemental restraints circuit (1 of 3) -> BRN WIRE
