Audi S5 I facelift (2011-2016) automatic transmission hydraulic pressure sensor 1 Wiring diagrams
This page contains all the electrical diagrams for the component. automatic transmission hydraulic pressure sensor 1, in which he is found in the car Audi S5 I facelift (2011-2016). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram automatic transmission hydraulic pressure sensor 1 (1 of 2)
ACCESS/START AUTHORIZATION BUTTON
AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 1
AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 2
BLK/VIO WIRE
BLU WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DIRECT SHIFT GEARBOX (DSG) TRANSMISSION MECHATRONIC
DIRECT SHIFT GEARBOX (DSG) TRANSMISSION MECHATRONIC (IN TRANSMISSION HOUSING)
ENGINE CONTROL MODULE (ECM)
ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER)
FUSE 1
FUSE 10
FUSE 12
FUSE CARRIER 1
FUSE CARRIER 1 FUSE 12
FUSE PANEL C
FUSE PANEL C (LEFT END OF DASH)
GEAR POSITION DISTANCE SENSOR 1
GEAR POSITION DISTANCE SENSOR 2
GEAR POSITION DISTANCE SENSOR 3
GEAR POSITION DISTANCE SENSOR 4
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES RELAY/FUSE FUSE 1 PANEL B (IN LEFT PLENUM CHAMBER E-BOX)
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED FUSE CARRIER 1 FUSE 10
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
RED/BRN WIRE
RELAY/FUSE PANEL B)
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE (ATTACHED TO SHIFT LEVER ASSEMBLY)
TEMPERATURE SENSOR (IN CONTROL MODULE)
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION FLUID TEMPERATURE SENSOR 2
TRANSMISSION PARK SELECTOR SWITCH, SHIFT LOCK SOLENOID
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
Go to component -> A/t circuit (1 of 3) -> AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 1
Wiring diagram automatic transmission hydraulic pressure sensor 1 (2 of 2)
4.2L 3.2L
ACCESS/START AUTHORIZATION BUTTON (W/ START/STOP BUTTON)
AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 1
AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 2
BLK/BRN WIRE
BLK/VIO WIRE
BLU/BLK WIRE
BLU/GRY WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (RIGHT REAR OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DIRECT SHIFT GEARBOX (DSG) MECHATRONIC (AT TRANSMISSION)
ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER)
FUSE 1
FUSE PANEL SC (UNDER LEFT SIDE OF DASH)
GEAR POSITION DISTANCE SENSOR 1
GEAR POSITION DISTANCE SENSOR 2
GEAR POSITION DISTANCE SENSOR 3
GEAR POSITION DISTANCE SENSOR 4
GRN/GRY WIRE
GRN/VIO WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED FUSE CARRIER 1 FUSE 10
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
POWER DISTRIBUTION SYSTEM
PRNDS
RELAY/FUSE CARRIER E BOX SB (IN LEFT PLENUM CHAMBER E-BOX)
SELECTOR LEVER SENSOR SYSTEM CONTROL MODULE
TEMPERATURE SENSOR (IN CONTROL MODULE)
TRANSMISSION CONTROL MODULE (TCM)
TRANSMISSION PARK SELECTOR SWITCH, SHIFT LOCK SOLENOID
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (ON RELAY & FUSE PANEL)
Go to component -> A/t circuit, with direct shift (1 of 2) -> AUTOMATIC TRANSMISSION HYDRAULIC PRESSURE SENSOR 1
