Audi S5 I facelift (2011-2016) a/c control head climatronic control module Wiring diagram
This page shows the only wiring diagram for the component.a/c control head climatronic control module, which is found in the car Audi S5 I facelift (2011-2016). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram a/c control head climatronic control module (1 of 1)
2.0L TURBO
3.0L
3.2L
4.2L
A/C CONTROL HEAD CLIMATRONIC CONTROL MODULE
A/C CONTROL HEAD CLIMATRONIC CONTROL MODULE (BEHIND CENTER OF DASH)
ACTIVE STEERING CONTROL MODULE (DRIVER'S FOOTWELL)
ACTIVE STEERING CONTROL MODULE (UNDER DRIVER'S SEAT)
ALL WHEEL DRIVE CONTROL MODULE (SPECIAL EQUIPMENT) (IN SPARE TIRE
ALL- WHEEL DRIVE CONTROL MODULE
ASR/ESP BUTTON
BLK WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/VIO WIRE
BLK/YEL WIRE
BRAKE LIGHT SWITCH
BRAKE LIGHT SWITCH (ON BRAKE PEDAL ASSEMBLY)
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE CONTROL MODULE (ECM)
ENGINE CONTROL MODULE (ECM) (IN LEFT PLENUM CHAMBER)
ESP SENSOR UNIT 2
FUSE 10
FUSE 3
FUSE CARRIER 1
FUSE CARRIER 1 FUSE
FUSE CARRIER 2
FUSE CARRIER 2 FUSE
FUSE CARRIER 3 FUSE
FUSE PANEL C
FUSE PANEL C (LEFT END OF DASH)
FUSE PANEL SC (UNDER LEFT SIDE OF DASH)
FUSE PANEL SD (UNDER RIGHT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/RED WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
ORG/BLU WIRE
ORG/BRN WIRE
ORG/WHT WIRE
RED WIRE
RED/BLK WIRE
RED/BRN WIRE
RIGHT FRONT ABS WHEEL SPEED SENSOR
RIGHT FRONT ABS WHEEL SPEED SENSOR (ON RIGHT FRONT WHEEL HUB)
RIGHT REAR ABS WHEEL SPEED SENSOR
RIGHT REAR ABS WHEEL SPEED SENSOR (ON RIGHT REAR WHEEL HUB)
W/ NAVIGATION
W/ NAVIGATION SYSTEM
WELL, FORWARD OF BATTERY)
WHT/BLK WIRE
YEL WIRE
Go to component -> Anti-lock brakes circuit (2 of 3) -> A/C CONTROL HEAD CLIMATRONIC CONTROL MODULE
