Awd circuit, w/ torque vectoring for Audi S4 B9 (2016-2019)
Awd circuit, w/ torque vectoring
ALL WHEEL DRIVE CLUTCH VALVE
ALL WHEEL DRIVE CLUTCH VALVE 2
ALL WHEEL DRIVE PUMP
BLK WIRE
BLK/VIO WIRE
BRN WIRE
BRN/GRN WIRE
COMPUTER DATA LINES SYSTEM
DIFFERENTIAL LOCK CONTROL MODULE
FUSE 10
FUSE PANEL 5
FUSE PANEL F
GRN/WHT WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
OIL PRESSURE/ TEMPERATURE SENSOR
OIL PRESSURE/ TEMPERATURE SENSOR 2
PNK/WHT WIRE
RED WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 2
SUPPLEMENTAL RESTRAINTS SYSTEM
VIO/RED WIRE
WHT WIRE
WHT/YEL WIRE
YEL WIRE
YEL/RED WIRE
