Heated seats circuit, w/ ventilation for Audi S4 B9 (2016-2019)
Heated seats circuit, w/ ventilation (1 of 2)
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
DRIVER SEAT BACKREST COUPLING POINT
FUSE 1
FUSE PANEL 3
FUSE PANEL 4
FUSE PANEL B
GRN WIRE
GRN/BRN WIRE
HOT AT ALL TIMES
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
LEFT FRONT SEAT BACKREST FAN 1
LEFT FRONT SEAT COUPLING STATION
LEFT FRONT SEAT CUSHION FAN 1
LEFT FRONT SEAT HEATED BACKREST
LEFT FRONT SEAT HEATING ELEMENT, LEFT FRONT SEAT TEMPERATURE SENSOR
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/YEL WIRE
RELAY & FUSE CARRIER 1
VIO/WHT WIRE
WHT/YEL WIRE
YEL WIRE
Heated seats circuit, w/ ventilation (2 of 2)
BLK WIRE
BLK/WHT WIRE
BRN WIRE
BRN/WHT WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE SEAT VENTILATION SWITCH
FRONT A/C DISPLAY CONTROL HEAD
FRONT PASSENGER SEAT BACKREST COUPLING POINT
FRONT PASSENGER SIDE SEAT VENTILATION SWITCH 2
GRN WIRE
GRN/BRN WIRE
LEFT SEAT HEATING BUTTON
ORG/BRN WIRE
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/YEL WIRE
RIGHT FRONT SEAT BACKREST FAN 1
RIGHT FRONT SEAT COUPLING STATION
RIGHT FRONT SEAT CUSHION FAN 1
RIGHT FRONT SEAT HEATED BACKREST
RIGHT FRONT SEAT HEATING ELEMENT, RIGHT FRONT SEAT TEMPERATURE SENSOR
RIGHT SEAT HEATING BUTTON
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
