Wiring diagram engine performance 3.0l turbo, structure borne sound actuator circuit for Audi S4 B9 (2016-2019)
Wiring diagram engine performance 3.0l turbo, structure borne sound actuator circuit
BRN WIRE
COMPUTER DATA LINES SYSTEM
ENGINE SOUND GENERATOR ACTUATOR 1
ENGINE SOUND GENERATOR CONTROL MODULE
FUSE 3
FUSE PANEL 4
FUSE PANEL B
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
HOT W/ TERMINAL 15 POWER SUPPLY RELAY ENERGIZED
ORG/BRN WIRE
REAR OF ENGINE COMPT)
RELAY & FUSE CARRIER 1
STRUCTURE BORNE SOUND ACTUATOR
STRUCTURE BORNE SOUND CONTROL MODULE
WHT/BLK WIRE
YEL/VIO WIRE
