Anti-lock brakes circuit for Audi S4 B9 (2016-2019)

ABS CONTROL MODULE (LEFT FRONT OF ENGINE COMPT) ABS CONTROL MODULE FUSE 1 ABS CONTROL MODULE FUSE 2 ABS HYDRAULIC PUMP ABS HYDRAULIC UNIT BLK WIRE BLK/VIO WIRE BLK/WHT WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/WHT WIRE CLUTCH POSITION SENSOR COMPUTER DATA LINES SYSTEM DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 1 DRIVING DYNAMICS REGULATION HIGH PRESSURE SWITCH VALVE 2 DRIVING DYNAMICS REGULATION SWITCH VALVE 1 DRIVING DYNAMICS REGULATION SWITCH VALVE 2 FUSE 11 FUSE PANEL 2 FUSE PANEL B GRN WIRE GRN/VIO WIRE GRY/BLK WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES LEFT FRONT ABS INLET VALVE LEFT FRONT ABS OUTLET VALVE LEFT FRONT ABS WHEEL SPEED SENSOR LEFT PARKING BRAKE MOTOR LEFT REAR ABS INLET VALVE LEFT REAR ABS OUTLET VALVE LEFT REAR ABS WHEEL SPEED SENSOR M/T PNK WIRE RED WIRE RED/BLK WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE CARRIER 1 RIGHT FRONT ABS INLET VALVE RIGHT FRONT ABS OUTLET VALVE RIGHT FRONT ABS WHEEL SPEED SENSOR RIGHT PARKING BRAKE MOTOR RIGHT REAR ABS INLET VALVE RIGHT REAR ABS OUTLET VALVE RIGHT REAR ABS WHEEL SPEED SENSOR SUPPLEMENTAL RESTRAINTS SYSTEM VACUUM SENSOR WHT WIRE YEL WIRE YEL/GRN WIRE

A/T ASR/ESP BUTTON AUTO- HOLD BRN WIRE BRN/BLU WIRE BULB BUTTON COMPUTER DATA LINES SYSTEM DRIVING, CONVENIENCE FUNCTIONS CONTROL UNIT 1 ELECTRO- MECHANICAL ELECTRO-MECHANICAL PARKING BRAKE BUTTON (M/T) FUSE 3 FUSE 6 FUSE PANEL 2 FUSE PANEL 3 FUSE PANEL B GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES ILLUMINATION INDICATOR LAMP INSTRUMENT CLUSTER SYSTEM M/T ORG/BRN WIRE PARKING BRAKE RED/GRN WIRE RED/WHT WIRE RELAY & FUSE CARRIER 1 VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE YEL WIRE

2.0L TURBO DBPA 2.0L TURBO CYMC 3.0L TURBO ABS INDICATOR LAMP AUTO HOLD BUTTON (A/T) AUTO- HOLD BLK WIRE BRAKE FLUID LEVEL WARNING SWITCH BRAKE LAMP SWITCH (BRAKE MASTER CYLINDER) BRAKE SYSTEM INDICATOR LAMP BRN WIRE BRN/BLU WIRE BULB COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM DISPLAY UNIT ELECTRO- MECHANICAL ELECTRO-MECHANICAL PARKING BRAKE BUTTON (A/T) ENGINE/MOTOR CONTROL MODULE FUSE 11 FUSE 12 FUSE 5 FUSE 9 FUSE PANEL 1 FUSE PANEL B FUSE PANEL C GRN WIRE GRN/BLK WIRE GRN/VIO WIRE GRN/YEL WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/BRN WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED ILLUMINATION INDICATOR LAMP INSTRUMENT CLUSTER CONTROL MODULE ORG/BRN WIRE PARKING BRAKE PNK WIRE POWER DISTRIBUTION SYSTEM RED/VIO WIRE RED/WHT WIRE RED/YEL WIRE RELAY & FUSE CARRIER 1 STEERING ANGLE SENSOR STEERING COLUMN ELECTRONICS CONTROL MODULE STEERING COLUMN) VIO WIRE VIO/RED WIRE VIO/YEL WIRE YEL WIRE
