Front heated seats circuit, without memory seats without ventilation for Audi S4 B8 facelift (2011-2015)
Front heated seats circuit, without memory seats without ventilation
BACKREST HEATING ELEMENT
BACKREST SIDE BOLSTER HEATER (IF EQUIPPED)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CLIMATRONIC CONTROL MODULE
COMPUTER DATA LINES SYSTEM
DRIVER'S BACKREST HEATING ELEMENT
DRIVER'S SEAT HEATER LEFT FRONT SEAT TEMP SENSOR
FRONT PASSENGER'S BACKREST HEATING ELEMENT
FRONT PASSENGER'S SEAT HEATER
FUSE
FUSE CARRIER 2
FUSE PANEL C (BEHIND LEFT END OF DASH)
GRN WIRE
GRN/BRN WIRE
HEATED DRIVER'S SEAT ADJUSTER
HEATED FRONT PASSENGER'S SEAT ADJUSTER
HOT AT ALL TIMES
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RIGHT FRONT SEAT TEMP SENSOR
SEAT BOLSTER HEATER (IF EQUIPPED)
SEAT HEATING ELEMENT
SIDE BOLSTER HEATER (IF EQUIPPED)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
WHT WIRE
YEL WIRE
YEL/BLU WIRE
