Front heated seats circuit, with memory seats with ventilation for Audi S4 B8 facelift (2011-2015)
Front heated seats circuit, with memory seats with ventilation
BACKREST HEATING ELEMENT
BLK WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
DRIVER POWER SEAT ADJUSTMENT CIRCUIT BREAKER 1
DRIVER'S BACKREST HEATING ELEMENT
DRIVER'S SEAT BACKREST BLOWER FAN (TOP OF DRIVER SEAT BACKREST)
DRIVER'S SEAT BACKREST BLOWER FAN 2 (MIDDLE OF DRIVER SEAT BACKREST)
DRIVER'S SEAT CUSHION BLOWER FAN (UNDER FRONT OF DRIVER SEAT CUSHION)
DRIVER'S SEAT CUSHION BLOWER FAN 2 (UNDER REAR OF DRIVER SEAT CUSHION)
DRIVER'S SEAT HEATER
GRN WIRE
HOT AT ALL TIMES
LEFT FRONT SEAT TEMP SENSOR
MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE (UNDER DRIVER'S SEAT)
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
SEAT BOLSTER HEATER
SEAT HEATING ELEMENT
WHT WIRE
YEL WIRE
