Audi S4 B8 facelift (2011-2015) right swivel module position sensor Wiring diagram
This page shows the only wiring diagram for the component.right swivel module position sensor, which is found in the car Audi S4 B8 facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right swivel module position sensor (1 of 1)
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/VIO WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 7 FUSE 6
FUSE CARRIER 1
FUSE PANEL C (BEHIND LEFT END OF DASH)
GRN WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRY/RED WIRE
GRY/VIO WIRE
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LEFT FRONT FOG LAMP
POWER OUTPUT STAGE
RIGHT ADAPTIVE CORNERING LIGHT MOTOR
RIGHT DAYTIME RUNNING LAMPS, PARKING LAMP CONTROL MODULE (IF EQUIPPED)
RIGHT DAYTIME RUNNING LAMPS, PARKING LAMP LED MODULE (IF EQUIPPED)
RIGHT FRONT FOG LAMP
RIGHT FRONT HEADLAMP
RIGHT FRONT SIDE MARKER LAMP (SPECIAL EQUIPED)
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR
RIGHT HEADLAMP POWER OUTPUT STAGE
RIGHT HIGH INTENSITY GAS DISCHARGE (HID) LAMP
RIGHT HIGH INTENSITY GAS DISCHARGE (HID) LAMP CONTROL MODULE
RIGHT LOW BEAM REFLECTOR MOTOR
RIGHT SIDE MARKER LAMP
RIGHT STATIONARY OUTPUT STAGE
RIGHT SWIVEL MODULE POSITION SENSOR
WHT WIRE
WHT/BLU WIRE
WHT/GRY WIRE
Go to component -> Headlights circuit, with bi-xenon, with cornering headlights (2 of 2) -> RIGHT SWIVEL MODULE POSITION SENSOR
