Audi S4 B8 facelift (2011-2015) premium standard Wiring diagram
This page shows the only wiring diagram for the component.premium standard, which is found in the car Audi S4 B8 facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram premium standard (1 of 1)
BRN WIRE
CD/DVD CHARGER
DRIVER'S DOOR CONTROL MODULE
DRIVER'S SIDE CAN SEPARATING PLUG
GRN WIRE
GRN/VIO WIRE
INFORMATION ELECTRONIC CONTROL MODULE 1
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
POWER STEERING CONTROL MODULE
PREMIUM STANDARD
SEAT VENTILATION CONTROL UNIT (DRIVER) (UNDER DRIVER'S SEAT CUSHION)
TELEPHONE TRANSCEIVER (UNDER FRONT PASSENGER'S SEAT)
TRANSMISSION CONTROL MODULE (IN MECHATRONIC UNIT)
TV TUNER (LEFT SIDE OF TRUNK)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
VIO WIRE
VIO/YEL WIRE
YEL WIRE
YEL/GRY WIRE
