Audi S4 B8 facelift (2011-2015) cargo area) Wiring diagram
This page shows the only wiring diagram for the component.cargo area), which is found in the car Audi S4 B8 facelift (2011-2015). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cargo area) (1 of 1)
BLK/YEL WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/BLK WIRE
BRN/RED WIRE
BRN/WHT WIRE
CARGO AREA)
COMPUTER DATA LINES SYSTEM
FRONT PARKING AID WARNING BUZZER (UNDER CENTER CONSOLE)
FUSE CARRIER 3 FUSE
FUSE PANEL C (BEHIND LEFT END OF DASH)
GRY/WHT WIRE
HOT AT ALL TIMES
INDICATOR
LEFT FRONT CENTER PARKING AID SENSOR (IN RADIATOR GRILLE)
LEFT FRONT PARKING AID SENSOR (IN FRONT BUMPER)
LEFT REAR CENTER PARKING AID SENSOR (ON REAR BUMPER)
LEFT REAR PARKING AID SENSOR (ON REAR BUMPER)
ORG/BLK WIRE
ORG/BRN WIRE
PARKING AID BUTTON
PARKING AID SWITCH
REAR PARKING AID WARNING BUZZER (LEFT SIDE OF
RED/BRN WIRE
RED/GRN WIRE
RED/YEL WIRE
RIGHT FRONT CENTER PARKING AID SENSOR
RIGHT FRONT PARKING AID SENSOR (FRONT BUMPER)
RIGHT REAR CENTER PARKING AID SENSOR (ON REAR BUMPER)
RIGHT REAR PARKING AID SENSOR (ON REAR BUMPER)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (UNDER LEFT SIDE OF DASH)
W/ NAVIGATION
W/O NAVIGATION
YEL/RED WIRE
Go to component -> Parking assistant circuit -> CARGO AREA)
