Navigation circuit, mmi 3 standard for Audi S4 B8 (2008-2011)

"C" PILLAR) 16 7 18-PIN CONNECTOR ANTENNA AMPLIFIER 3 BLK WIRE BLK/WHT WIRE BLU/GRN WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE BRN/VIO WIRE BRN/YEL WIRE COMFORT SYSTEM CENTRAL CONTROL MODULE COMPUTER DATA LINES SYSTEM FUSE CARRIER 3 GRN/VIO WIRE HOT AT ALL TIMES FUSE 3 HOT AT ALL TIMES FUSE 4 LEFT QUARTERPANEL) LUGGAGE COMPARTMENT RELAY/FUSE CARRIER LUGGAGE COMPT) MOST DATA BUS CIRCUIT NCA WIRE OF LUGGAGE COMPT) OF TRUNK) PILLAR) RADIO RED/BLU WIRE RED/VIO WIRE RED/YEL WIRE RIGHT FRONT MID-BASS SPEAKER RIGHT FRONT TREBLE SPEAKER RIGHT REAR MID/ LOW RANGE SPEAKER RIGHT REAR TREBLE SPEAKER TV TUNER (IF EQUIPPED) WHT WIRE WHT/GRN WIRE

BLK/WHT WIRE BLU/WHT WIRE BRN WIRE BRN/BLU WIRE CD/DVD CHANGER CENTER TUNNEL) COMPUTER DATA LINES SYSTEM DIGITAL RADIO ANTENNA ANTENNA AMPLIFIER 2 END OF DASH) FUSE 1 FUSE CARRIER 2 GRN/VIO WIRE HOT AT ALL TIMES INFORMATION ELECTRONICS CONTROL MODULE 1 LEFT FRONT MID-BASS SPEAKER LEFT FRONT TREBLE SPEAKER LEFT REAR MID/ LOW RANGE SPEAKER LEFT REAR TREBLE SPEAKER MOST DATA BUS CIRCUIT NAVIGATION SYSTEM ANTENNA NCA WIRE OF ROOF) PASSENGER'S SIDE FUSE PANEL RADIO, TELEPHONE NAVIGATION SYSTEM ANTENNA RED/BLK WIRE RED/BLU WIRE SATELLITE ANTENNA TELEPHONE ANTENNA TELEPHONE BASE PLATE W/ BLUETOOTH W/ SPEAKER PHONE
