Audi S4 B8 (2008-2011) transmission assembly Wiring diagram

This page shows the only wiring diagram for the component.transmission assembly, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram transmission assembly (1 of 1)

Wiring diagram transmission assembly for Audi S4 B8 (2008-2011)

Get access

CLUTCH OIL TEMPERATURE SENSOR DRIVE POSITION SENSOR MAIN PRESSURE VALVE NCA WIRE OIL COOLING VALVE SUB-TRANSMISSION 1 VALVE 1 SUB-TRANSMISSION 1 VALVE 2 SUB-TRANSMISSION 1 VALVE 3 SUB-TRANSMISSION 1 VALVE 4 SUB-TRANSMISSION 2 VALVE 1 SUB-TRANSMISSION 2 VALVE 2 SUB-TRANSMISSION 2 VALVE 3 SUB-TRANSMISSION 2 VALVE 4 TRANSMISSION ASSEMBLY TRANSMISSION INPUT SPEED (RPM) SENSOR 1 TRANSMISSION INPUT SPEED (RPM) SENSOR 2 TRANSMISSION INPUT SPEED (RPM) SENSOR 3

Go to component: -> A/t circuit, with direct shift (2 of 2) -> TRANSMISSION ASSEMBLY
