Audi S4 B8 (2008-2011) steering column) electronic steering column lock control module Wiring diagram
This page shows the only wiring diagram for the component.steering column) electronic steering column lock control module, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering column) electronic steering column lock control module (1 of 1)
ACCESS/START AUTHORIZATION SWITCH
AUXILIARY HEATER CONTROL MODULE
BEHIND STEERING WHEEL)
CLIMATRONIC CONTROL MODULE
COMFORT SYSTEM CENTRAL CONTROL MODULE
DOOR WINDOW REGULATOR MOTOR)
EXTERNAL AUDIO SOURCE CONNECTION
FRONT PASSENGER'S DOOR CONTROL MODULE
GRN/VIO WIRE
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PARALLEL PARKING ASSISTANCE CONTROL MODULE
PASSENGER'S SIDE CAN SEPERATING PLUG
RADIO
SIDE OF TRUNK) (IF EQUIPPED) REAR VIEW CAMERA SYSTEM CONTROL MODULE
STEERING COLUMN ELECTRONIC SYSTEM CONTROL MODULE
STEERING COLUMN) ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
TIRE PRESSURE MONITORING CONTROL MODULE
VIO/BLU WIRE
VIO/YEL WIRE
W/ MMI 2 GENERATOR W/ MMI 3 GENERATOR
W/ MMI HIGH
Go to component: -> Computer data lines circuit (3 of 3) -> STEERING COLUMN) ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
