Audi S4 B8 (2008-2011) seat occupied sensor Wiring diagram
This page shows the only wiring diagram for the component.seat occupied sensor, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram seat occupied sensor (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
FUSE
FUSE CARRIER 3
FUSE CARRIER 4
GRN WIRE
GRY/BLU WIRE
HEATED SEAT TEMP SENSOR
HEATED SEAT TEMP SENSOR SEAT OCCUPIED SENSOR
HOT AT ALL TIMES
LEFT REAR BACKREST HEATING ELEMENT
LEFT REAR HEATED SEAT REGULATING SWITCH
LEFT REAR SEAT HEATER
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER
LUGGAGE COMPT)
OF RIGHT "C" PILLAR)
RED WIRE
RIGHT REAR BACKREST HEATING ELEMENT
RIGHT REAR HEATED SEAT REGULATING SWITCH
RIGHT REAR SEAT HEATER
SEAT HEATER
SEAT OCCUPIED SENSOR
SEDAN: RIGHT SIDE OF CENTER TUNNEL)
SIDE OF DASH)
STORAGE COMPT)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/RED WIRE
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component: -> Front seat heater circuit, without ventilation -> SEAT OCCUPIED SENSOR
