Audi S4 B8 (2008-2011) seat back) Wiring diagrams
This page contains all the electrical diagrams for the component. seat back), in which he is found in the car Audi S4 B8 (2008-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
seat back) wiring diagram (1 of 2)
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR
DRIVER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR
DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
DRIVER'S SIDE FUSE PANEL
END OF DASH)
FRONT PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR
FRONT PASSENGER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
FRONT PASSENGER'S SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR
FRONT SEAT BACK)
HOT AT ALL TIMES FUSE FUSE CARRIER 3
LUMBAR CURV- ATURE
LUMBAR HEIGHT
RED WIRE
SEAT BACK)
SEDAN: BASE OF RIGHT "C" PILLAR)
SEDAN: BEHIND LEFT KICK PANEL)
Go to component -> Lumbar circuit -> SEAT BACK)
seat back) wiring diagram (2 of 2)
BACKREST
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT BREAKER 1
DRIVER POWER SEAT ADJUSTMENT
DRIVER'S BACKREST ADJUSTMENT MOTOR
DRIVER'S POWER SEAT SWITCH
DRIVER'S SEAT FORE/AFT ADJUSTMENT MOTOR
DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR
DRIVER'S SEAT INCLINATION ADJUSTMENT MOTOR
DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
DRIVER'S SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR
DRIVER'S SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR
FORE/ AFT
FORE/AFT
FRONT PASSENGER POWER SEAT ADJUSTMENT
FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
FRONT PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR
FRONT PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR
FRONT PASSENGER'S BACKREST ADJUSTMENT MOTOR
FRONT PASSENGER'S POWER SEAT SWITCH
FRONT PASSENGER'S SEAT FORE/AFT ADJUSTMENT MOTOR
FRONT PASSENGER'S SEAT HEIGHT ADJUSTMENT MOTOR
FRONT PASSENGER'S SEAT INCLINATION ADJUSTMENT MOTOR
FRONT SEAT BACK)
HEIGHT
HOT AT ALL TIMES
OF DRIVER SEAT CUSHION)
OF PASSENGER SEAT CUSHION)
PASSENGER FRONT SEAT BACK)
RED WIRE
SEAT BACK)
SEDAN: BASE OF RIGHT "C" PILLAR)
SEDAN: BEHIND LEFT KICK PANEL)
TILT
WHT WIRE
YEL WIRE
Go to component -> Power seats circuit -> SEAT BACK)
