Audi S4 B8 (2008-2011) radio frequency controlled clock Wiring diagram
This page shows the only wiring diagram for the component.radio frequency controlled clock, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radio frequency controlled clock (1 of 1)
ABS WARNING LAMP IND
AIR BAG MALFUNCTION INDICATOR LAMP (MIL)
ASR/ ESP CONTROL LAMP IND
BRN WIRE
BRN/BLK WIRE
BRN/GRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
END OF DASH)
FUEL LEVEL SENSOR 2 (IF EQUIPPED)
FUEL LEVEL SENSOR, TRANSFER FUEL PUMP (FP)
HOT AT ALL TIMES FUSE FUSE 5 CARRIER 2
OF DASH)
ORG/BLU WIRE
ORG/BRN WIRE
PASSENGER'S SIDE FUSE PANEL
RADIO FREQUENCY CONTROLLED CLOCK
RADIO FREQUENCY CONTROLLED CLOCK RECEIVER
RED WIRE
RED/BRN WIRE
RED/GRY WIRE
SEDAN: LEFT SIDE OF CENTER TUNNEL)
SPEEDOMETER INSTRUMENT CLUSTER CONTROL MODULE
TACHOMETER
VIO/BLK WIRE
VIO/RED WIRE
YEL WIRE
Go to component: -> Instrument cluster circuit -> RADIO FREQUENCY CONTROLLED CLOCK
