Audi S4 B8 (2008-2011) passenger's side fuse Wiring diagram
This page shows the only wiring diagram for the component.passenger's side fuse, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's side fuse (1 of 1)
18 PIN CONNECTOR (W/O SPEAKER PHONE)
BLK WIRE
BLU WIRE
BLU/VIO WIRE
BLU/YEL WIRE
BLUETOOTH ANTENNA
BRN WIRE
CENTER TUNNEL)
COMPUTER DATA LINES SYSTEM
END OF DASH)
FRONT INFORMATION DISPLAY CONTROL HEAD
FUSE CARRIER 2 FUSE 3
FUSE FUSE 3 CARRIER 3
GRN WIRE
GRN/VIO WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES LUGGAGE COMPARTMENT RELAY/FUSE CARRIER FUSE 5
INFORMATION ELECTRONICS CONTROL MODULE 1
LEFT MICROPHONE
MICROPHONE UNIT
MMI BASIC
MMI HIGH
MOST DATA BUS CIRCUIT
MULTIMEDIA CONTROL HEAD
NCA WIRE
OF DASH)
OF LUGGAGE COMPT)
ORG/ WIRE
PANEL)
PASSENGER'S SIDE FUSE
RED WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RIGHT MICROPHONE
SIDE OF CENTER TUNNEL)
STORAGE COMPT)
TELEPHONE BASEPLATE (W/ SPEAKER)
TELEPHONE BASEPLATE (W/O SPEAKER)
VEHICLE ELECTRIC SYSTEM CONTROL MODULE
VIO RED/ WIRE
VIO/YEL WIRE
W/ SPEAKER
W/ W/O SPEAKER SPEAKER
W/O SPEAKER
WHT WIRE
YEL WIRE
Go to component: -> Multimedia interface circuit (1 of 2) -> PASSENGER'S SIDE FUSE
