Audi S4 B8 (2008-2011) left high beam headlamp wiring diagram
This page shows the only wiring diagram for the component.left high beam headlamp, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
left high beam headlamp wiring diagram (1 of 1)
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE FUSE PANEL
EMERGENCY FLASHER INDICATOR LAMP EMERGENCY FLASHER BUTTON
END OF DASH)
FOG LAMP 3 2 1 4 BUTTON DIMMER SW
FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP
FUSE 10 FUSE 8
FUSE 4
FUSE CARRIER 2
FUSE CARRIER 3
FUSE CARRIER 4 FUSE 12
GRN WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/RED WIRE
GRY/YEL WIRE
HEADLAMP RIGHT LOW BEAM
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERM 15) ENERGIZED
INSTRUMENT CLUSTER CONTROL MODULE
LAMP
LAMP RIGHT PARKING
LEFT DAYTIME
LEFT FRONT FOG LAMP
LEFT FRONT SIDE MARKER LAMP
LEFT FRONT TURN
LEFT HEADLIGHT ASSEMBLY
LEFT HIGH BEAM HEADLAMP
LEFT LOW BEAM HEADLAMP
LEFT PARKING
LIGHT SWITCH
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER
LUGGAGE COMPT)
MARKER LAMP
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER'S SIDE FUSE PANEL
REAR FOG LAMP BUTTON
RED/VIO WIRE
RED/YEL WIRE
RIGHT DAYTIME
RIGHT END OF DASH)
RIGHT FRONT FOG LAMP
RIGHT HEADLIGHT ASSEMBLY
RIGHT HIGH BEAM HEADLAMP
RUNNING LIGHT
SEDAN: BEHIND RIGHT KICK PANEL)
SEDAN: LEFT SIDE OF CENTER TUNNEL)
SENSOR PACKAGE)
SIDE OF DASH)
SIGNAL LAMP
SIGNAL LAMP RIGHT FRONT TURN
SIGNAL/SIDE LEFT FRONT TURN
STORAGE COMPT)
SUPPLEMENTAL RESTRAINTS SYSTEM
VALET PARKING INDICATOR LAMP VALET PARKING LOCK BUTTON
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/VIO WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Headlights circuit, with standard headlights -> LEFT HIGH BEAM HEADLAMP
