Audi S4 B8 (2008-2011) left front seat temp sensor Wiring diagram

This page shows the only wiring diagram for the component.left front seat temp sensor, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram left front seat temp sensor (1 of 1)

Wiring diagram left front seat temp sensor for Audi S4 B8 (2008-2011)

Get access

ADJUSTMENT BACKREST HEATER BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE CIRCUIT BREAKER 1 DRIVER POWER SEAT DRIVER SEAT BACKREST) DRIVER'S BACKREST HEATING ELEMENT DRIVER'S SEAT BACKREST FAN DRIVER'S SEAT BACKREST FAN 2 DRIVER'S SEAT CUSHION FAN DRIVER'S SEAT CUSHION FAN 2 DRIVER'S SEAT HEATER GRN WIRE HOT AT ALL TIMES LEFT FRONT SEAT TEMP SENSOR MEMORY SEAT/STEERING COLUMN ADJUSTMENT CONTROL MODULE OF DRIVER SEAT CUSHION) RED WIRE RED/BLK WIRE RED/YEL WIRE SEAT HEATER SEDAN: BEHIND LEFT KICK PANEL) SIDE BOLSTER HEATER WHT WIRE YEL WIRE

Go to component: -> Front seat heater circuit, with memory seats with ventilation -> LEFT FRONT SEAT TEMP SENSOR
