Audi S4 B8 (2008-2011) left front body acceleration sensor Wiring diagram
This page shows the only wiring diagram for the component.left front body acceleration sensor, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left front body acceleration sensor (1 of 1)
ACTIVE STEERING CONTROL MODULE
BLK WIRE
BLK/YEL WIRE
BRN WIRE
CHARISMA SWITCH MODULE
COMPUTER DATA LINES SYSTEM
FUSE CARRIER 1 FUSE
FUSE CARRIER 3 FUSE
FUSE PANEL SC
GRN/BLU WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LEFT FRONT BODY ACCELERATION SENSOR
LEFT FRONT LEVEL CONTROL SYSTEM SENSOR
LEFT REAR LEVEL CONTROL SYSTEM SENSOR
ORG/BLU WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/WHT WIRE
REAR BODY ACCELERATION SENSOR
RED/BLU WIRE
RED/VIO WIRE
RIGHT FRONT BODY ACCELERATION SENSOR
RIGHT REAR LEVEL CONTROL SYSTEM SENSOR
SID OF DASH)
SIDE OF SIDE OF CENTER CENTER TUNNEL) TUNNEL)
STORAGE COMPT)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/GRN WIRE
VIO/RED WIRE
VIO/YEL WIRE
W/O NAVIGATION SYSTEM W/ NAVIGATION SYSTEM
WHT WIRE
WHT/BLU WIRE
WHT/BRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
YEL/BLK WIRE
YEL/GRY WIRE
YEL/WHT WIRE
Go to component: -> Electronic suspension circuit (2 of 2) -> LEFT FRONT BODY ACCELERATION SENSOR
