Audi S4 B8 (2008-2011) lane change Wiring diagram
This page shows the only wiring diagram for the component.lane change, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lane change (1 of 1)
BLK/BRN WIRE
BLK/GRN WIRE
BLK/RED WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRN WIRE
BRN/GRN WIRE
CHANGE LANE
COMPUTER DATA LINES SYSTEM
DIRECTIONAL STABILIZATION ASSISTANCE CONTROL MODULE
DIRECTIONAL STABILIZATION ASSISTANCE WINDSHIELD HEATER
DRIVER'S EXTERIOR MIRROR ASSEMBLY
DRIVER'S SIDE FUSE PANEL
FUSE CARRIER 1 FUSE 4
FUSE CARRIER 4 FUSE 10
GRY/BLU WIRE
HOT W/ POWER SUPPLY RELAY (TERMINAL 15) ENERGIZED
LANE CHANGE
LANE CHANGE ASSISTANCE BUTTON
LANE CHANGE ASSISTANCE CONTROL MODULE
LANE CHANGE ASSISTANCE CONTROL MODULE 2
LEFT END OF DASH)
LUGGAGE COMPARTMENT RELAY/FUSE CARRIER
LUGGAGE COMPT)
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRY WIRE
PASSENGER'S EXTERIOR MIRROR ASSEMBLY
SEDAN: BEHIND LEFT KICK PANEL)
SIDE OF LUGGAGE COMPT)
SIDE OF LUGGAGE COMPT) COMPUTER DATA LINES SYSTEM
TAILLIGHT ASSEMBLY)
VIO/YEL WIRE
YEL WIRE
YEL/BLU WIRE
