Audi S4 B8 (2008-2011) lamp/drl module Wiring diagram
This page shows the only wiring diagram for the component.lamp/drl module, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram lamp/drl module (1 of 1)
BLK/GRN WIRE
BLK/VIO WIRE
BLU/RED WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER'S SIDE FUSE PANEL
END OF DASH)
FUSE 6
FUSE CARRIER 1
GRN WIRE
GRN/BLK WIRE
GRN/BRN WIRE
GRN/GRY WIRE
GRN/WHT WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/RED WIRE
GRY/VIO WIRE
GRY/YEL WIRE
HEADLIGHT RANGE CONTROL MODULE (BEHIND GLOVE BOX)
HOT W/ POWER SUPPLY RELAY (TERM 15) ENERGIZED
LAMP/DRL MODULE
LEFT FRONT FOG LAMP
LEFT FRONT LEVEL CONTROL SYSTEM SENSOR (W/O ELECTRONIC DAMPING)
LEFT REAR LEVEL CONTROL SYSTEM SENSOR (W/O ELECTRONIC DAMPING)
MARKER LAMP
ORG/BLK WIRE
ORG/BRN WIRE
RIGHT FRONT FOG LAMP
RIGHT FRONT SIDE
RIGHT FRONT TURN SIGNAL LAMP
RIGHT HEADLAMP BEAM ADJUSTMENT MOTOR
RIGHT HEADLIGHT ASSEMBLY
RIGHT HIGH INTENSITY GAS DISCHARGE (HID) LAMP
RIGHT HIGH INTENSITY GAS DISCHARGE LAMP CONTROL MODULE
RIGHT LED PARKING
RIGHT LOW BEAM REFLECTOR MOTOR
RIGHT PARKING LAMP
SEDAN: BEHIND LEFT KICK PANEL)
SEDAN: BEHIND RIGHT KICK PANEL)
VIO/BRN WIRE
VIO/RED WIRE
VIO/YEL WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
Go to component: -> Headlights circuit, with bi-xenon without cornering headlights (2 of 2) -> LAMP/DRL MODULE
