Audi S4 B8 (2008-2011) front passenger power seat adjustment Wiring diagram
This page shows the only wiring diagram for the component.front passenger power seat adjustment, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger power seat adjustment (1 of 1)
BACKREST
BLK WIRE
BLU WIRE
BRN WIRE
CIRCUIT BREAKER 1
DRIVER POWER SEAT ADJUSTMENT
DRIVER'S BACKREST ADJUSTMENT MOTOR
DRIVER'S POWER SEAT SWITCH
DRIVER'S SEAT FORE/AFT ADJUSTMENT MOTOR
DRIVER'S SEAT HEIGHT ADJUSTMENT MOTOR
DRIVER'S SEAT INCLINATION ADJUSTMENT MOTOR
DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
DRIVER'S SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR
DRIVER'S SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR
FORE/ AFT
FORE/AFT
FRONT PASSENGER POWER SEAT ADJUSTMENT
FRONT PASSENGER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
FRONT PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR
FRONT PASSENGER SEAT LUMBAR SUPPORT HEIGHT ADJUSTMENT MOTOR
FRONT PASSENGER'S BACKREST ADJUSTMENT MOTOR
FRONT PASSENGER'S POWER SEAT SWITCH
FRONT PASSENGER'S SEAT FORE/AFT ADJUSTMENT MOTOR
FRONT PASSENGER'S SEAT HEIGHT ADJUSTMENT MOTOR
FRONT PASSENGER'S SEAT INCLINATION ADJUSTMENT MOTOR
FRONT SEAT BACK)
HEIGHT
HOT AT ALL TIMES
OF DRIVER SEAT CUSHION)
OF PASSENGER SEAT CUSHION)
PASSENGER FRONT SEAT BACK)
RED WIRE
SEAT BACK)
SEDAN: BASE OF RIGHT "C" PILLAR)
SEDAN: BEHIND LEFT KICK PANEL)
TILT
WHT WIRE
YEL WIRE
Go to component: -> Power seats circuit -> FRONT PASSENGER POWER SEAT ADJUSTMENT
