Audi S4 B8 (2008-2011) driver's side fuse panel fuse carrier 3 Wiring diagram

This page shows the only wiring diagram for the component.driver's side fuse panel fuse carrier 3, which is found in the car Audi S4 B8 (2008-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..

Wiring diagram driver's side fuse panel fuse carrier 3 (1 of 1)

Wiring diagram driver's side fuse panel fuse carrier 3 for Audi S4 B8 (2008-2011)

Get access

BLK WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER'S SIDE FUSE PANEL FUSE CARRIER 3 END OF DASH) FUSE 7 GRY WIRE HOT AT ALL TIMES INSTRUMENT CLUSTER CONTROL MODULE KICK PANEL) LEFT FRONT BRAKE PAD WEAR SENSOR ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/GRY WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE

Go to component: -> Brake wear sensor circuit -> DRIVER'S SIDE FUSE PANEL FUSE CARRIER 3
